Automatic pneumatic chamfer machine of double end for steel pipes/tubes/rods

FOB Price

US$ 6,000 - 7,000 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	CARE		Place of Origin	Jiangsu, China
Model Number	DEF-FA/52 chamfer machine of double end		After-sales Service Provided	Engineers available to service machinery overseas

Automatic pneumatic chamfer machine of double end for steel pipes/tubes/rods

Main specification

It is easy to adjust the cutting feeding speed.

Dies clamper and cutter head are special designed, can finish internal angle, external angle and flat angle at the same time.

Rotate speed can be adjustable according to the change of belt pulley, suit for all kinds of metal material pipes.

Technical parameter

MODEL	DEF-FA/52
SPEC.	DEF-FA/52
Main motor	2x1.5kw/4P (for steel, iron tube/pipe)
	2x1.5kw/1.0, 2/4P (for aluminum, bronze)
	2×1/0.75kw,4/8P (for SS)
Hydraulic motor	2HPx4P
Air pressure	0.6-0.8Mpa, 120ml/min.
Cutter head range	Φ9-Φ50mm for steel pipe Φ9-Φ25mm for steel rod
Workpiece length	18-700mm

Machine photo

Clamp molds

Cutter plate

Pipe/rod sample

To know more information, please contact us at any time.
