CNC Aluminum processing machine
Feature
◆ For curtain walls, aluminium profiles and so on.
◆ Drilling and milling functions.
◆ Spindle: Italy HSD, 18000 rpm/min.
◆ Industrial personal computer: Taiwan ADVANTECH.
◆ Servo motor and driver: Japan OMRON.
◆ Ball screw and square guide rail: Japan ABBA.
◆ A axis rotate the work piece between -90°and +90°according to request, so it is available to columnar work piece.
◆ Half dry cooling system, with plant oil, no damage to workers and environment.
◆ Continue to work from the breakpoint.
◆ Equipped with professional software CAD-CAM.
◆ Light curtain to protect workers effectively.
◆ Lock Knife block is convenient to change cutters.
Parameter
Power: 380V/50Hz/11kw
Air pressure: 0.5-0.8Mpa
X axis stroke: 3600mm
X axis speed: 120m/min
Y axis stroke: 380mm
Y axis speed: 80m/min
Z axis stroke: 400mm
Z axis speed: 60m/min
Max. processing speed: 3m/min
Location error: ±0.05mm
Resetting error: ±0.02mm
Processing error: ±0.1mm
Surface roughness: Ra12.5μm
Overall dimension: 5380x1890x2240mm
Weight: 3000kg
Pre-Sales Service
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
After-Sales Service
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
Founded in 2003, Parker Machinery Co., Ltd has developed an assembly line for door, window, curtain wall and insulating glass equipment. With over ten years' production experience, Parker has become a leading manufacturer of window door machinery in China. The operation of high precision, advancement and specialty ensure that we are able to supply high-quality window and door equipment for customers.
During the past few years, Parker has made great progress and has become well known and outstanding in domestic fairs for window door machinery. With advanced technological equipment, tremendous technical strength and reliable product quality, our window and door equipment has been well received by customers from Russian, Kazakhstan, Vietnam, Iran, etc. We have a perfect sales network and complete service system in China. We are also taking a leading role in setting branch companies abroad.
4 Axis CNC Machining Center
The machine is suitable for processing installation holes, water slot, shaped holes, and end milling and making screw on curtain walls and aluminum windows and doors.
5 Axis CNC Machining Center
PKG 5 This equipment is suitable for precision machining of large-scale workpieces such as aerospace, automobile, textile, mold, packaging machinery, mining equipment, and can finish the complicated processing of milling, drilling, boring and tapping.
Parker high speed drilling and milling machine center DMCC82
The machine is suitable for processing installation holes, water slot, shaped holes, and end milling and making screw on curtain walls and aluminum windows and doors.
