argon gas filling machine/Double glazed glass inactive gas filler machine/Double glazed glass fabrication machine (ZCJ02)
1.Product Description
1).It is special equipment for gas charging in insulating glass production.
2).Available for aluminum spacer insulating glass and rubber strip insulating glass.
3).Adopting imported microcomputer controller and high quality components, the equipment are automatically, stable and reliable.
4).With compact size and four universal wheels on the base, it is flexible and convenient in use.
5).It can charge two units of glass at a same time.
2.Technical parameters
Model number |
ZCJ02 |
Power voltage |
220V |
Power frequency |
50HZ |
Total power |
0.1KW |
Maximum number of insulating glass |
2 units |
Volume of argon flow |
0-15L/min |
Overall dimensions |
810 x 420 x 760mm |
Weight |
40kg |
3.Model ZCJ02(two head argon filling machine) photo
Kindly note:
1)the argon filling machine, we can make one head argon filling machine, two head argon filling machine, four head argon filling machine, we can make according to your requirements.
2).If making the insulating glass, only use the desiccant is not enough for making sure 100% vacuum, so to charge argon into the double glass inner is best.
4.Four head argon filling machine photo
5.Insulating glass/double glass/hollow glass good advantages
1).sound insulation, noise reduction
2).keep warm
3).dust prevention
4).reduce thermal radiation
6. Related insulating glass processing flow chart
Besides you buy the basic vertical production line, you also need to add some accesary machines, such as Butyl extruder machine, two component coating machine, alu-spacer cutting saw, glass adge polishing machine etc.
About the full insulating glass production steps, here I can give you a brief introduction for your reference:
If you want to save some cost about the vertical production line, you can consider to by these basic machines is enough:
1).insulating glass/double glass/hollow glass production line, model: LB1800P
2). Butyl glue extruder machine, model : JT01
3).Two component glue coating machine, model: ST01
4).Rotary coating machine, model: SZT01 (this machine together work with the two component glue coating machine)
5).Glass edge polishing machine, model: SM95
7.Insulating glass/double glass product
8.Insulating glass structure
9. Contact information
