16 Ton Single Drum Roller CLG616 Vibratory Road Roller
US$ 35,800 - 68,000
/ Unit
1 Unit(Min. Order)
- Shanghai port
- T/T Credit Card
You May Like
-
6 m Asphalt Paver Finisher RP602 New Asphalt Pavers for Sale
-
New Sensor Asphalt Paver Models RP602 Sale in Philippines
-
Brand New 6 m RP602 Asphalt Concrete Paver Parts
-
1.2 Milling Width Asphalt Cold Mlling Machine for Sale
-
2019 Hot Sale RP602 Asphalt Concrete Paver Machine
-
China Asphalt Concrete Road Paver Machine RP903
Product Details
| Brand Name | liugong | Place of Origin | Guangxi, China | |
| Type | Single Drum Roller | Certification | ISO | |
| Weight | 16000kg | |||
| Dimension(L*W*H) | 6198*2300*3058mm | Condition | New | |
| Power(W) | 110KW | Grade Ability | 30% | |
| Travel Speed | 0-10Km/h |
Product Description
16 ton single drum roller CLG616 vibratory road roller
Contact way
Sales Manager
Alisa Wang
Newindu E-Commerce (Shanghai) Co.,Ltd.
Add: Suite 1326, Fortune Times Tower, No. 1438 North Shanxi Road, Shanghai, China
Tel: +86-21-62770109 Fax: +86-21-62120109
Mobile / Whatsapp/ Skype/Wechat/skype: +86-18616224775
Add: Suite 1326, Fortune Times Tower, No. 1438 North Shanxi Road, Shanghai, China
Tel: +86-21-62770109 Fax: +86-21-62120109
Mobile / Whatsapp/ Skype/Wechat/skype: +86-18616224775
Alibaba Website: https://cnnewindu.en.china.cn/
Product Description
16 ton single drum roller CLG616 vibratory road roller
| Mass | Operating Mass(kg) | 16000 | |
| Mass On Vibrating Drum(kg) | 8300 | ||
| Mass On Drive Axle(kg) | 7700 | ||
| Front Drum Static Linear Load (N/cm) | 382 | ||
| Compaction | Vibration Frequency(Hz) | 30 | |
| Nominal Amplitude(mm) | 1.9/1.0 | ||
| Centrifugal Force(kN) | 300/160 | ||
| Drum Diameter(mm) | 1500 | ||
| Drum Width(mm) | 2130 | ||
| Drum Thickness(mm) | 30 | ||
| Drive | 1st Maximum Speed,fwd(km/h) | 2.6 | |
| 2nd Maximum Speed,fwd(km/h) | 5.2 | ||
| 3rd Maximum Speed,fwd(km/h) | 11 | ||
| 4th Maximum Speed,fwd(km/h) | |||
| Theoretical Gradeability(%) | 30 | ||
| Min. Ground Clearance(mm) | 430 | ||
| Wheelbase(mm) | 3100 | ||
| Steering Angle(°) | ±35 | ||
| Swing angle(°) | ±10 | ||
| Min. Outside Turning Radius(mm) | 6500 | ||
| Tyre Type | 20.5-25-16PR | ||
| Tyre Pressure(kPa) | 300-330 | ||
| Overall Length(mm) | 6145 | ||
| Overall Width(mm) | 2300 | ||
| Overall Height(mm) | 3040 | ||
| Engine | Brand | Yuchai | |
| Model | YC6B150Z-T21 | ||
| Emission Regulation | TierⅡ | ||
| Rated Power(kW) | 110 | ||
| Rated Rotation Speed(r/min) | 2100 | ||
| Theoretical Fuel Consumption(g/kW.h) | 228 | ||
| Torque(N.m) | 550 | ||
| Number of Cylinders | 6 | ||
| Displacement(L) | 8.27 | ||
| Aspiration | Turbocharged | ||
| Cooling Type | Water | ||
| Volume | Battery(V/Ah) | 24/200 | |
| Alternator(V/A) | 28/45 | ||
| Rear Axle(L) | 20 | ||
| Vibrating Housing(L) | 2.3×2 | ||
| Fuel Tank(L) | 285 | ||
| Hydraulic Oil Tank(L) | 120 | ||
| Engine Oil(L) | 19 | ||
| Transimission/Torque Converter(L) | 14.5 | ||
| Coolant(L) | 32 | ||
| Tyre Wetting(L) | 415×2 | ||
| Weight on Front Axle(T) | |||
| Weight on Rear Axle | |||
| Padfoot | Padfoot Thickness(mm) | 18 | |
| Padfoot Height(mm) | 80 | ||
| Unit Area of Per Padfoot(cm2) | 110 | ||
| Grounding Area(cm2) | 612 | ||
| Number of Padfoot | 132 | ||
| Gross Weight of Padfoot(kg) | 1100 | ||
