Home > Products > Road Construction Machinery > Good Price RP953 Asphalt Concrete Paver Finisher
Good Price RP953 Asphalt Concrete Paver Finisher
- Shanghai
- T/T Credit Card
You May Like
Product Details
| Brand Name | Newindu | Place of Origin | Jiangsu, China | |
| Certification | ISO CE | |||
| Warranty | 1 Year | Weight | 22500~30800 kg | |
| Dimension(L*W*H) | 6610*2600*3950 mm | Production Capacity | 700 t/h | |
| Condition | New | Power(W) | 150 | |
| Max. Paving Thickness | 320mm |
Product Description
Good Price RP953 Asphalt Concrete Paver Finisher
Aring Zhou
Email: aring @newindu.com
Wechat/Mobile/Whatsapp: +86 15855426352
Skype: zyy1520724641 @outlook.com
| Item | RP953 | Unit |
| Basic Paving Width | 2.5 | m |
| Max. Paving Width | 10.5 | m |
| Max. Paving Thickness | 400 | mm |
| Paving Speed | 0~18 | m/min |
| Travel Speed | 0~2.8 | km/h |
| Theoretically Productivity | 900 | t/h |
| Hopper Capacity | 15 | t |
| Gradeability | 20 | % |
| Flatness | 0.8 | mm/3m |
| Error of Lateral Slope | ±0.2 | % |
| Adjusting Range of Camber | -1~+4 | % |
| Diesel Engine Model | BF6M1013 | |
| Diesel Engine Power | 159 | kw |
| Diese Engine Speed | 2200 | r/min |
| Total Weight | 22.8~30 | t |
| Overall Dimension | 6790*2600*3950 | mm |
| Material Conveying Speed | 0~22 | m/min |
| Material Distributing Speed | 0~90 | r/min |
| Vibration Speed | 0~1400 | r/min |
| Screed Heating | Air heating | |
| Conveyor and Transfer Material-Level Control Way | Ultrasonic sensing automatic control | |
| Automatic Leveling Control Way | Analog control | |
RP953 asphalt concrete pavers to "technology leadership, stable and reliable performance, environmental protection and energy conservation" for the design concept, in the technical performance, construction quality, the use of economic and operational comfort have reached a world-class level. The product is mainly used for all levels of road surface paving, can also be used for all levels of highway paving.
1. Configuration of the original German water-cooled supercharged engine, the engine power is strong, mature and reliable.
2. Configuration four in one strong composite radiator, through the concentration of intelligent cooling, sub-tank diversion, can guarantee the whole machine in the environment at high temperature of 50 ℃ for a long time continuous work.
3. Running around the independent drive, digital microcomputer control, constant speed automatic control technology.
4. The input material adopts four sets of independent hydraulic actuators, and the material level adopts ultrasonic sensing control technology to realize the whole proportion of the material supply.
5. The left and right feeding device can be easily moved up and down as a whole, can adapt to different paving thickness, reduce material segregation.
6. The material is made of high wear-resistant alloy material, and the bottom plate and screed bottom plate are imported with high wear-resistant steel plate.
7. Intelligent leveling technology, has a good human-computer interaction interface, easy maintenance, environmental protection and energy conservation, high reliability and wide adaptability and so on.
8. Automatic leveling the use of imported German digital angle leveling machine, higher accuracy.
9. Equipped with double vibrating eccentric vibrating machine.
10. Centralized lubrication system can automatically evenly to the high temperature parts of the bearing oil.
11. The machine has the advantages of high degree of automation, simple operation, good construction quality and high operation efficiency.
