China Mini 135HP Motor Grader for Sale
US$ 38,000 - 39,000
/ Unit
1 Unit(Min. Order)
- Shanghai/Qingdao
- T/T Credit Card
You May Like
-
GR135/GR180 135HP 180HP Motor Grader for Sale
-
XS143J XS163J 16 Ton Single Drum Road Roller for Sale
-
High Quality Mini GR165 65HP Motor Grader for Sale
-
Mini New Vibratory Road Roller Compactor XD132 for Satisfactory Price
-
2019 XP303 Mini Road Roller Compactor for Sale
-
XP262 New Pneumatic Tyred Road Roller for Sale
Product Details
| Brand Name | NEWINDU | Certification | ISO | |
| Dimension(L*W*H) | 8015*2380*3050mm | |||
| Condition | New | Reverse Speed(km/h) | 40 | |
| Forward Speed(km/h) | 42 |
Product Description
China Mini 135HP Motor Grader for Sale
Please Contact
Aring Zhou
Email: aring at
Wechat/Whatsapp/Mobile: +86 15855426352
Skype: zyy1520724641at
Main Parameters
Basic Specification
| Model | GR135 |
| Engine Model | 6BT5.9 |
| Rated Power/Speed | 100/2200kw/rpm |
| Dimension(L*W*H) | 8015*2380*3050mm |
| Operating Weight | 11000kg |
Main Performance
| Travelling Speed(forward) | 5,8,13,20,30,42km/h |
| Travelling Speed(reverse) | 5,13,30km/h |
| Tractive Force(f=0.75) | 61.3kN |
| Max.Gradeability | 20% |
| Tire Inflation Pressure | 300kPa |
| Working Hydraulic Pressure | 16MPa |
| Transmission Pressure | 1.3-1.8MPa |
Operating Specification
| Max. steering angle of front wheels | ±49° |
| Max. lean angle of front wheels | ±17° |
| Max. oscillation angle of front axle | ±15° |
| Max. oscillation angle of balance box | 16 |
| Frame articulation angle | ±27° |
| Min. turning radius using articulation | 6.6m |
Biade
| Maximum lift above ground | 410mm |
| Maximum depth of cutting | 535mm |
| Maximum blade position angle | 90° |
| Blade cutting angle | 28°-70° |
| Circle reversing rotation | 360° |
| Moldboard width X height | 3710*610mm |
