DG5033A Elisa Reader/Enzyme-linked Immunosorbent Assay

DG5033A Elisa Reader/Enzyme-linked immunosorbent assay

Introduction

DG5033A type enzyme immunoassay instrument is advanced and user-friendly design concept combines high-tech products. The product uses industrial computer control, large-screen color LCD, data processing capacity greatly improved, so have the accurate and reliable, fast and stable superior performance in many similar products alone lead the 21st century trend of the first digital design. Its powerful database functionality and innovative human-computer interaction platform, giving the user an extremely flexible, unique personality experience. With its superior product performance and quality of similar products at home and abroad outstanding, Zoran superior. The device is widely used in major hospitals, research institutions and universities, the Centers for Disease Control, Bureau of Quality Supervision and the food and feed industry, can be carried out to detect hepatitis A, hepatitis B, hepatitis C, AIDS, melamine, aflatoxin and other projects.

Feature

1 Output data transmission: general EXECL form type
2 Calculation mode: open qualitative judgment, quantitative analysis, by using L universal formula of critical value by the user according to the need
3 To adjust, suitable for different manufacturers reagent requirements, with linear regression, remove the fitting, logarithmic, double, single point calibration
4 Logarithmic, percentage concentration and other quantitative analysis function
5 Update: software can not regular free upgrades for life
6 Repeatability: standard coefficient of variation CV of 0.7% or less
7 Software functions
8 Stability: plus or minus 0.7% or less
9 Panel layout: visual 96 hole horizontal and vertical cloth plate at any position, any set up blank control, masculine control location

Technical Parameter

 1 Light source: halogen tungsten lamp (12 v, 20 w) average life 5000 hours or more
 2 Detector: silicon photocell hamamatsu (Japan)
 3 Enzyme label plate formats: standard 96, or 48 hole enzyme label plate
 4 Wavelength range: 400-750 nm
 5 Filter configuration: 405, 450, 492, 450 mm accuracy: plus or minus 2 nm, 7 mm or less bandwidth, other wavelengths can be selected
 6 Reading range: 0.000-4.000 Abs
 7 Measurement methods: full automatic single and dual wavelength (vertical light channel end point method, many kinds of quantity and the computing model
8 Calculation mode: measuring range value, adjustable threshold and other qualitative analysis (including S/CO, P/N, N/P, inhibition rate, open L = aP + bN + c, etc.) and quantitative analysis (single point calibration, linear regression, a multipoint line, semi logarithmic fitting,
