FYY-3 Molecular Hybridization Instrument

FYY-3 molecular hybridization instrument

 Introduction

The instrument adopts the microcomputer intelligent control, liquid crystal display three functions (temperature, rotation speed, the tray rack swing speed). With memory function, can display the running status of the system. Temperature control system based on digital PID technology, the PWM output, high precision of temperature control, good stability, and is equipped with over temperature protection device, the equipment can directly control box temperature, rolling bottle rack rotation speed, swing speed enzyme label plate or reagent tray. At the same time, the arbitrary choice of temperature control of what you need, bottle rack rotation speed, swing speed table.

Technical indicators

1 temperature range, the ambient temperature of +5 DEG -100 DEG adjustable.

2 temperature accuracy of 0.1 DEG C

3 - 0.03 DEG C temperature uniformity

4 hybrid speed 0-15 / or 0-24 / adjustable

Table 5: 5-50 times / min swing frequency adjustable

6 hybrid tank capacity: the diameter of 42mm and length of 150mm (6)

Diameter of 42mm and length of 200mm (6)

Diameter of 42mm and length of 250mm (6).

7 hybrid bottle rotating frame can be replaced by a centrifugal tube rotating frame. At the same time placed 1.5ml tube 32, 32 5ml centrifuge tube, 8 15ml tube.

Studio 8 dimensions: 270 x 270 x 310mm.

9 hybrid process in the hybrid continuous rotation of the bottle, film and probe completely mixed, thus completely avoid the leakage of radioactive isotope hybridization and cumbersome packaging bag. The studio has the function of radiation protection, patent design, a machine with three, in addition to the molecular hybridization, also can do incubator and air bath with shaking table
