JRY-JFC12 Automatic Flip-type Extractor
- shenzhen
- T/T Credit Card
You May Like
-
OTF-1200X-RTP-II Evaporation Coating Furnace CSS Furnace for Rapid Thermal Processing
-
MiniT-H2C / MiniT-H3 Dry Bath Incubator
-
PTL-UMB Micron Range Programmable Dip Coater (1-500 Um/sec) With Drying Oven Upto 200 Degree Vacuum Drying Oven
-
K30 Dry Bath Incubator
-
HNC-3200DTD Ultrasonic Cleaning Machine
-
GSL-1600X-42HG Hydrogen Tube Furnace
Product Details
| Brand Name | HUNANJINRONGYUAN-Y | Place of Origin | Shaanxi, China | |
| Model Number | JRY-JFC12 | Power | Electronic | |
| Usage | Auto Testing Machine |
Product Description
JRY-JFC12 automatic flip-type extractor
Introduction
JRY automatic flip-type extractor is a chemical used in the solid extraction apparatus and extracted by the bottle, fixtures, variable speed motors, temperature control, time control, six major rotating system. It works by variable speed motor allows the extraction agent in the extraction bottle top to bottom, from bottom to flip back and forth, so that the extraction agent and water samples and full knot fierce collision, in order to achieve the purpose of extraction, while the entire extraction extraction in a closed bottle to complete a thorough solution to the problem of volatile reagents, make the results more reliable extraction, data extraction authentic.
JRY automatic flip-type extraction application areas: environmental monitoring, petrochemicals, water companies, sewage treatment plants, power plants, steel companies, automobile manufacturing, research and teaching laboratories and various medium-sized enterprises Stations.
Feature
1) Closed extraction reagent volatile solve problems and avoid direct contact with the laboratory personnel and toxic extraction reagents.
2) Samples shock effect, high extraction efficiency, true and reliable analysis results.
3) each batch can be simultaneously extracted more than 12 samples.
4) All stainless steel shell, elegant, easy to clean.
5) Push protective cover, leakproof sink hole design to ensure the safe operation of equipment.
6) plexiglass observation window, visible and transparent, functioning at a glance.
7) Reliable safety device with overload protection, leakage protection, protective cover open automatic power-off function.
8) the extraction time can be arbitrarily set, adjustable flip mode.
9) special fixtures fixed to ensure that the vial securely.
10) compatibility, and can be placed on a variety of extraction vessel sizes and materials (optional).
Technical Parameter
Model | JRY-FC12 | JRY-FC24 | JRY-FC36 | JRY-FC48 |
Sample No.Quanlity | 12 piece | 24 piece | 36 piece | 48 piece |
Sample bottle volume | 10ml-1000ml/bottle | |||
Fixed Power | 220 V,50HZ | |||
Motor power | 90 W | 120 W | 140 W | 160 W |
Rotatably method (1) | Unidirectional / Bidirectional | |||
Rotating Speed | 0~60 r/min adjustable | |||
Temperature control range | Indoor temperature ~65℃ | |||
Time Control(2) | 0~24 h | |||
Reversible Time Control | Customers can freely set forward, reverse, stop time | |||
Dimension | 800X550X700 | 980X550X700 | 1160X550X700 | 1400X550X700 |
Total weight | 45 kg | 55 kg | 65 kg | 75 kg |
Material | All stainless steel housing | |||
Tips | Special specifications can be customized according to customer requirements | |||
