New products hot sale all alloy aluminum conductor rubber cable for welding machine

FOB Price

USD $0.15 - $25 / Meter

3000 Meters(Min.Order)

Supply Ability 500 Kilometer / Kilometers per Month
Port Tian jin port Qing dao Port Shanghai port
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Brand Name:	RNE DA	Place of Origin:	Hebei, China	Model Number:	YH YHF, YH/YHF
Type:	Low Voltage	Insulation Material:	Rubber
Jacket:	Rubber	Conductor Material:	Copper

Product Description

New products hot sale all alloy aluminum conductor rubber cable for welding machine

Professional OEM manufacturer

Top ten cable manufactuer in China

WITH UL,TUV,KEMA,CE,BV,PSB,SABA CERTIFICATIONS

WITH TUV TYPE TESTING REPORT

ISO9001,ISO18001,OHSAS18001

1.Standard

the welding cable can be produced according to the standard 245 IEC 81,ICEA S-75-381

2.Specific Property for Using

(1).The cable can be used in the connectors of electric weld and pliers of the electrical welding whose toward earth voltage of the low voltage is not more than AC 200 V and the pulsant DC peak value is 400V.
(2).The long-time permissible working temperature of cable is not more than 65.

3.Name and IEC Standard
(1).Rubber Sheathed Welding Cable 245 IEC 81
(2).Rubber Sheathed Welding Cable 245 IEC 82,which is made of chloroperene or the composite stretchy materials.

4. Conductor Materials: Copper, Tinned Copper,all aluminum alloy conductor

5. Jacket: Rubber

6. Applications: For Welding Machines and so on

7.The general data of the cable 245 IEC 81 and 245 IEC 82

Conductor Nominal Section (mm2)	Conductive Core	Thickness of Section Sheath (mm)	Average Outer Diameter (mm)		20oC Conductor Resistance ≤(Ω/km)	Reference Weight (kg/km)
Conductor Nominal Section (mm2)	Number/Diameter of Core(mm)	Thickness of Section Sheath (mm)	Min	Max	20oC Conductor Resistance ≤(Ω/km)	YH	YHF
10	322/0.20	1.8	7.5	9.7	1.91	146	153.51
16	513/0.20	2.0	9.2	11.5	1.16	218.9	230.44
25	798/0.20	2.0	10.5	13.0	0.758	316.6	331.15
35	1121/0.20	2.0	11.5	14.5	0.536	426	439.87
50	1596/0.20	2.2	13.5	17.0	0.379	592.47	610.55
70	2214/0.20	2.4	15.0	19.5	0.268	790	817.52
95	2997/0.20	2.6	17.0	22.0	0.198	1066.17	1102.97
120	1702/0.30	2.8	19.0	24.0	0.161	1348.25	1392.55
150	2135/0.30	3.0	21.0	27.0	0.129	1678.5	1698.72
185	1443/0.40	3.2	22.0	29.0	0.106	1983.8	2020.74

Rubber flexible cable

Type and voltage	Description	Application	Test voltage (5min)
YG-300/500V	Heat-resisting silicon rubber insulated cable	Used for high-temperature site	2.0
60IEC53(YZ)300/500V	Rubber flexible cable	Used for various movable electrical equipment and tools
6024IEC57(YZW)300/500V	CR-jacketed flexible cable	Used for various movable electrical equipment and tools
60245IEC66(YCW)450/750V	Heavy-duty rubber flexible cable	Used for various movable electrical equipment and can withstand larger mechanical forces	2.5
60245IEC701(YTB)300/500V 60245IEC74(YT) 300/500V 60245IEC(YTF)300/500V	Braided lift cable high-strength rubber lift cable PCP rubber lift cable	Used for various elevators	2.0


60245IEC81(YH)	Common rubber sheathed cable for electric welding machine	Used for electric welding machine	1.0
60245IEC82(YHF)	PCP sheathed cable for electric welding machine	Used for electric welding machine	1.0
YQ,YQW300/500V	Light-duty rubber flexible cable	Used light duty movable electrical equipment and tools	2.0
YZ,YZW300/500V	Medium-duty rubber flexible cable
YZB,YZWB 300/500V	Medium-duty rubber flat flexible cable
YC,YCW450/750V	Heavy-duty rubber flexible cable	Used for various movable electrical equipment and can withstand larger mechanical forces	2.5
YHD 300/500V	Open country rubber insulated power cable	Used for various movable electrical equipment and tools in the open country	2.0

Details show

Packaging & Shipping

Company Information

Established in 1993, Hebei Huatong Wires and Cables Group Co., Ltd covers an area more than 220,000 square meters, owning more than 420 sets manufacturing equipment and more than 250 sets of testing equipment or apparatus. Our annual production capacity is 3 billion Chinese Yuan. Now there are more than 800 employers in our company, among which more than 150 are technicians. Our products are widely used in the field of electric power, coal, metallurgy, petrochemical industry, railway, national defense, construction, aviation and other national key projects.

Products: XLPE insulating power cables with voltage up to 35kV, PVC insulated power cables, mining cable, general rubber sheathed flexible cable, Submersible oil pump cable, locomotive-vehicle cables, elevator cable,shipboard cable, nuclear station cables, pre-fabricated branch cables, ABC cables, control cables, special cables, the motor winding connecting conductors, aluminum stranded conductor (AAC) and aluminum stranded steel-core reinforced conductor (ACSR) so on.

We are JV with Furukawa(Japanese company) for rubber serial cable (minding cables, welding cables.submersible oil pump cables, .)and also JV with Riken(Japanese company) for elevator cables. Our products have extensive influence and good reputation in both domestic and worldwide market, such as the United States, Holland, Italy, Russia, Britain, Australia, New Zealand, Ethiopia, Ghana, Algeria, South Africa,Congo, Middle East and Southeast Asia countries and so on.

Customer visit

Certification:

Our Services

1. 22 years production experience and 13 years export experience .

2.high-end Machinery and equipment for high quality cable .

3.manufacture various of cable :power cable,control cable,abc cable,submersible oil pump cable,rubber cable,elevator cable,electric cable...

4. products certification :UL,CE,BV,TUV,KEMA,PSB,SABS,ABS,NK,LR,KR,GL,DNV:

system ceryification:ISO9001,ISO14001,OHSAS18001

5.our product sells all over the world and has the good reputation.

fessional teamwork service for you actively.

7.quick solution and long time online time waiting for your inquiry.

8.rapid delivery and feedback.

9. Stock available, Free sample

10.We can do that you expect

FAQ

(1)When can I get the price?

We usually quote within 6 hours after we get your inquiry. If you are very urgent to get the price, pleasecall us or tell us in your e-mail so that we will regard your inquiry priority.

(2).How can I get a sample to check your quality?

After price confirmation, you can require for samples to check our quality. Sample is free, but the freightcharge should be paid.

(3).How long can I expect to get the sample?

After you pay the freight charge and send us confirmed files, the samples will be ready for delivery in 3-7days. The samples will be sent to you via express and arrive in 3~5 days. You can use your own express account or prepay us if you do not have an account.

(4).What about the lead time for mass production?

Honestly, it depends on the order quantity and the season you place the order.The best record we keep is delivering 10 kilometers cable within a week. Generally speaking, we suggest that you start inquiry two months before the date you would like to get the products at your country.

(5)What cables does Hua Tong manufature?XLPE insulating power cables with voltage up to 35kV, PVC insulated power cables, mining cable, general rubber sheathed flexible cable, Submersible oil pump cable, locomotive vehicle cables, elevator cable,shipboard cable, nuclear station cables, prefabricated branch cables, ABC cables, control cables, special cables, the motor winding connecting conductors, aluminum stranded conductor (AAC) and aluminum stranded steel-core reinforced conductor (ACSR) so on.

(6). Which payment terms do you accept?

A: The payment term varies with different price level and total value of every contract.

The following are most common terms:

a.100% TT advance for small amount orders.

b.30% T/T down payment, balance payment negotiable accordingly.
