Flame-retardent PVC insulation steel wire armoured aluminum power cable for coal miningtory
- 500 Kilometer / Kilometers per Month
- Tian jin port Qing dao port Shang hai port
- T/T Credit Card
- Rubber Insulated Cable, Flexible Cable Mining Cable MCP
- 3x1.0mm heating resistant silicone rubber cable/wire
- China supplier 8.7/10KV 3 core 300mm CU/XLPE/STA/PVC copper power mining cable
- Professional products flexible flat elevator crane cables
- Durable and Reliable Elevator Used Flexible Flat travel cable lift Cable
- UL3135 tinned copper Silicone rubber wire cable with Good quality
Product Details
Brand Name: | RNE DA | Place of Origin: | Hebei, China | Model Number: | MC,MCP,MCPJR |
Type: | Low Voltage | Insulation Material: | Rubber | ||
Jacket: | Rubber | Conductor Material: | Copper |
Product Description
Flame-retardent PVC insulation steel wire armoured aluminum power cable for coal miningtory
Product Description
Mining cable:
Brief introduction:
1 Rated voltage of the cables is divided into 6 grades, which is 0.3/0.5kV,0.38/.066kV,1.9/3.3kV,3.6/6kV,6/10kV.
2 There are allowed long-term working temperatures of the cable conductor. For the cable of U(M)CPT-0.66/1.14,
U(M)CPJB-0.66/1.14, U(M)CPJR-0.66/1.14 and 1.9/3.3kV, 3.6/6kV, 6/10kV, the temperature is 90℃;for the other, it is 65℃.
3 Minimum bending radius: For the cable of U (M)CPJB-0.66/1.14, U(M)CPJR-0.66/1.14,it is 15 times of the cable diameter;
for the others, it is 6 times of the cable diameters.
4 The grounding wire should be well connected with the earth.
5 The cable should be prevented from exposing to the sunshine for a long time.
Implemented standard:
1 For the non-spread combustion cable, implement GB12972
2 For the flame-retardant cable, implement MT818
3 For the special mining cable(with bigger cross-section and higher voltage),implement the enterprise standard.
Type and Name:
Type | Description | Application |
MC-0.38/0.66 | Rubber flexible cable for excavator | As the power connection used in the excavator or similar equipment with rated voltage 0.38/0.66kV |
MCP-0.38/0.66 | Shielded, rubber-sheathed flexible cable for excavator | As the power connection used in the excavator or similar equipment with rated voltage 0.38/0.66kV |
MCP-0.66/1.14 | Shielded, rubber flexible cable for excavator | As the power connection used in the excavator or similar equipment with rated voltage 0.38/0.66kV |
MCPJB-0.66/1.14 | Shielded ,monitoring and braiding reinforced type, rubber flexible cable for excavator | As the power connection used in the excavator or similar equipment with rated voltage 0.66/1.14kV, it can be dragged directly |
MCPJR-0.66/1.14 | Shielded ,monitoring and braiding reinforced type, rubber flexible cable for excavator | As the power connection used in the excavator or similar equipment with rated voltage 0.66/1.14kV, it must be used in the protective chain panel |
MCPT-0.66/1.14 | Metallic shielded rubber flexible cable for excavator | As the power connection used in the excavator or similar equipment with rated voltage 0.66/1.14kV |
MCP-1.9/3.3 | Shielded rubber flexible cable for excavator | As the power connection used in the excavator or similar equipment with rated voltage 1.9/3.3kV |
MCPT-1.9/3.3 | Metallic shielded rubber flexible cable for excavator | As the power connection used in the excavator or similar equipment with rated voltage 1.9/3.3kV |
MCPTJ-0.66/1.14 |
|
|
MCPTJ-1.9/3.3 | Metallic shielded, monitoring type, rubber flexible cable for excavator | As the power connection used in the excavator or similar equipment with rated voltage 1.9/3.3kV |
MY-0.38/0.66 | Movable rubber flexible cable for mining | As the power connection used in the mining machine with rated voltage 1.9/3.3kV |
MYP-0.38/0.66 | Movable shield rubber flexible cable for mining | As the power connection used in the mining machine with rated voltage 0.38/0.66kV |
MYP-0.66/1.14 | Movable shield rubber flexible cable for mining | As the power connection used in the mining machine with rated voltage 0.66/1.14kV |
MYPJ-3.6/6 | Monitoring movable shield rubber flexible cable for mining | As the power connection used in the mining transformer and similar equipment with rated voltage3.6/6kV |
MYPTJ-3.6/6 | Metallic shielded monitoring type movable rubber flexible cable | As the power connection used in the mining transformer and similar equipment with rated voltage3.6/6kV |
MYP-3.6/6 | Movable shield rubber flexible cable for mining | Mining equipment with rated voltage 3.6/6kV the min. environment temperature is-20℃ |
MYPT-3.6/6 | Movable metallic shield rubber flexible cable for mining | Mining equipment with rated voltage 3.6/6kV the min. environment temperature is-20℃ |
MYPD-3.6/6 | Movable shield rubber flexible cable for mining | Mining equipment with rated voltage 3.6/6kV the min. environment temperature is-40℃ |
MYPTD-3.6/6 | Movable metallic shield rubber flexible cable for mining | Mining equipment with rated voltage 3.6/6kV the min. environment temperature is-40℃ |
MZ-0.3/0.5 | Driller cable for mining | As the power connection of driller with rated voltage 0.3/0.5kV |
MZP-0.3/0.5 | Driller shielded cable for mining | As the power connection of driller with rated voltage 0.3/0.5kV |
MYQ-0.3/0.5 | Movable light-type rubber flexible cable for mining | Lighting in the mine, as the power connection of the interlock and control signals used in the transport machine and equipment |
Details Show
Shipping & Packaging
Company Introduction
HeBei huatong wires&cables Group Co.,ltd.It was established in 1993, we are JV with Furukawa(Japanese
company) for rubber serious cables and JV with Riken(Japanese company) for elevator cables. Besides these,our submersible oil pump cable and shipboard cable are very influential in domestic, and, the traditional cables are also produced such as PVC powercables, XLPE power cables, ABC cables, wires, control cables, screened cables,communication cables, conductors.We areOEM for many USA, Europen, Australia cable company,70% of our products are exported, most customers are from developed countries. We got ISO,UL,TUV,KEMA,CE and many other certifications.
Certification
We are one of China top rank cable&wire manufacturer.Our products meet standards of GB, IEC DIN ASTM, JIS, NF, AS/NZS CSA GOST and so on. At thte same time, we have obtained ISO9001,ISO14001,OHSAS18001, UL,CE,KEMA, TUV, Bureau Veritas, Lloyd,IEC,GL,SA,NK,KR certificates.
FAQ
(1).When can I get the price?
We usually quote within 6 hours after we get your inquiry. If you are very urgent to get the price, please
call us or tell us in your e-mail so that we will regard your inquiry priority.
(2).How can I get a sample to check your quality?
After price confirmation, you can require for samples to check our quality. Sample is free, but the freight
charge should be paid.
(3).How long can I expect to get the sample?
After you pay the freight charge and send us confirmed files, the samples will be ready for delivery in 3-7
days. The samples will be sent to you via express and arrive in 3~5 days. You can use your own express
account orprepay us if you do not have an account.
(4).What about the lead time for mass production?
Honestly, it depends on the order quantity and the season you place the order.The best record we keep is
delivering 10 kilometers cable within a week. Generally speaking, we suggest that you start inquiry two months
before the date you would like to get the products at your country.
