3x1.0mm heating resistant silicone rubber cable/wire

FOB Price

USD $0.5 - $60 / Meter

1000 Meters(Min.Order)

Supply Ability 1000000 Meter / Meters per Month
Port Tianjin Qingdao Shanghai or other main port
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Brand Name:	RNEDA	Place of Origin:	Hebei, China	Model Number:	H05SS-F
Type:	Low Voltage	Application:	Marine	Insulation Material:	Rubber
Jacket:	Rubber	Conductor Material:	Copper

Product Description

3x1.0mm Heating Resistant Silicone Rubber Cable/wire

1.Product Standard

This product is manufactured according to GB/5013,JB8735.

2.Application

1.Allowed long-term working temperature of the cable conductor:for silicon rubber insulated ,the highest temperature is 180℃,for the others,it is 60℃.

2.For the type of YQW,YAW,YCW,the cables have a good properties of oil-resistance and climate-resiatance,it is suitable used outdoor or the site with oil fouling .

3.Implemented standard

1).For the type of 60245IEC03(YG),implement GB5013.3 Heat-resistant, << silicon rubber insulated cable >>

2).For the type of 60245IEC53(YZ),60245IEC57(YZW),and 60245IEC66(YCW) implement GB5013.4

3).For the type of 60245IEC70(YTB),60245IEC74(YT),60245IEC75(YTF) implement GB5013.5<<evator cable >>.

4).For the type of 60245IEC81(YH),60245IEC82(YHF) implement GB5013.6<<cable for welding machine>>.

5).For the type of YQ,YQW,YZ,YZW,YZB,YZWB,YC,YCW implement JB8735.2 < <General rubber flexible cable >>.

4.Name,type and application

Type and voltage

Description

Application

YG-300/500V

Heat-resisting silicon

rubber insulated cable

Used for high-temperature site

60IEC53(YZ)300/500V

Rubber flexible cable

Used for various movable

electrical equipment and tools

6024IEC57(YZW)300/500V

CR-jacketed flexible

cable

60245IEC66(YCW)450/750V

Heavy-duty rubber

flexible cable

Used for various movable

electrical equipment and can

withstand larger mechanical forces

60245IEC701(YTB)300/500V

60245IEC74(YT)300/500V

60245IEC(YTF)300/500V

Braided lift cable

High-strength rubber

lift cable PCP rubber

lift cable

Used for electricity

60245IEC81(YH)

Common rubber sheathed

cable for electric

welding machine

Used for electric welding

machine

60245IEC82(YHF)

PCP sheathed cable for

electric welding

machine

YQ,YQW300/500V

Light-duty rubber

flexible cable

Used light duty movable

electrical equipment and tools

YZ,YZW300/500V

Medium-duty rubber

flexible cable

YZB,YZWB 300/500V

Medium-duty rubber flat

flexible cable

YC,YCW450/750V

Heavy-duty rubber

flexible cable

Used for various movable

electrical equipment and can

withstand larger mechanical

forces

YHD 300/500V

Open country rubber

insulated power cable

Used for various movable

electrical equipment and tools

in the open country

5. Product type and specification

Type	Rated voltage V	Number of cores	Normal section mm2
IEC03/YG	450/750	1,2,3,4,3+1	0.5-240
60245IEC70/YTB 60245IEC70/YT 60245IEC75/YTF	300/500	6,9,12,18,24,30	0.75,1
60245IEC81/YH 60245IEC82/YTH	-	1	16-95
60245IEC53/YZ	300/500	2,3,4,5	0.75-2.5
60245IEC57/YZW	300/500	2,3,4,5	0.75-2.5
YZ YZW	300/500	2,3,4,5	4-6
		4/3+1	1.5-6
		6	0.75-6
245IEC 66/YCW	450/750	1	1.5-400
		2	1.0-25
		3	1.0-95
		4	1.0-150
		5	1.0-25
YC		1	1.5-400
		2	1.5-95
		3	1.5-150
		5	1.5-25
		4/3+1	2.5-150
		5/3+2	2.5-150
YCW		2	35-95
		3	120-150
		4/3+1	2.5-150
		5/3+2	2.5-150
YHD	500	2,3,4	1.0-25
YHD	500	5,6,7,8	1.0-6

Details show

Details Show

Packaging & Shipping

Shipping & Packaging

Company Information

HeBei huatong wires&cables Group Co.,ltd.It was established in 1993, we are JV with Furukawa(Japanese company) for rubber serious cables and JV with Riken(Japanese company) for elevator cables. Besides these,our submersible oil pump cable and shipboard cable are very influential in domestic, and, the traditional cables are also produced such as PVC powercables, XLPE power cables, ABC cables, wires, control cables, screened cables,communication cables, conductors.We areOEM for many USA, Europen, Australia cable company,70% of our products are exported, most customers are from developed countries. We got ISO,UL,TUV,KEMA,CE and many other certifications.

Certifications

Certification

We are one of China top rank cable&wire manufacturer.Our products meet standards of GB, IEC DIN ASTM, JIS, NF, AS/NZS CSA GOST and so on. At thte same time, we have obtained ISO9001,ISO14001,OHSAS18001, UL,CE,KEMA, TUV, Bureau Veritas, Lloyd,IEC,GL,SA,NK,KR certificates.

FAQ

(1).When can I get the price?

We usually quote within 6 hours after we get your inquiry. If you are very urgent to get the price, please call us or tell us in your e-mail so that we will regard your inquiry priority.

(2).How can I get a sample to check your quality?

After price confirmation, you can require for samples to check our quality. Sample is free, but the freight charge should be paid.

(3).How long can I expect to get the sample?

After you pay the freight charge and send us confirmed files, the samples will be ready for delivery in 3-7 days. The samples will be sent to you via express and arrive in 3~5 days. You can use your own express account orprepay us if you do not have an account.

(4).What about the lead time for mass production?

Honestly, it depends on the order quantity and the season you place the order.The best record we keep is delivering 10 kilometers cable within a week. Generally speaking, we suggest that you start inquiry two months before the date you would like to get the products at your country.
