Help Center7001CTDULP4 7001-2RS ABEC3 Angular Contact Ball Bearing - 12x28x8mm
Related Products
-
7002 CDGA/P4A Full Ceramic Angular Contact Ball Bearing 15mm x 32mm X9mmUS$ 15 - 100MOQ: 1 Piece -
7003 ACD/HCP4A Angular Contact Ball Bearings, Super-precisionUS$ 100 - 1000MOQ: 1 Piece
-
Germany 71826 CDGA / P4A Ball Bearing Angular Contact , Single Row Spindle BearingUS$ 100 - 1000MOQ: 1 Piece
-
234406M 234706M Angular Contact Ball Bearing Application FactoryUS$ 100 - 1000MOQ: 1 Piece
-
234407M 234707M Angular Contact Bearings Advantages FactoryUS$ 100 - 1000MOQ: 1 Piece
7001CYP4 Angular Ball Bearing, Bearing is Precision Rolling, bearing is 15 degrees Contact Angle, Polyamide resin cage and Abec-7, Made in Japan, inner diameter is 12mm, outer diameter is 28mm and width is 8mm.
Item: 7001CYP4 Ball Bearing
Type: Nachi Angular Ball Bearing
Cage: Polyamide resin cage
Quality: ABEC-7
Dimensions: 12mm x 28mm x 8mm/Metric
ID (inner diameter)/Bore: 12mm
OD (outer diameter): 28mm
Width/Height/thickness: 8mm
Size: 12 x 28 x 8 mm
Quantity: One Bearing
| d | D | B | r | r1 | a |
| 12mm | 28mm | 8mm | 0.3mm | 0.15mm | -1.7mm |
7001CTDULP4 Super Precision 15 Degree Angular Contact Duplex ABEC7/P4 Phenolic Cage, Universal Mounting Light Preload Set Ball Bearings Open and pre-Lubricated with Oil
Price is for Pair of Bearings Set
Super Precision Angular Contact bearings are designed for rigid, high speed, high tolerance applications. Spindle bearings used in pairs in a 'back to back' or 'face to face' arrangement can support axial forces on both directions and moments. Bearings in a tandem arrangement can only support axial loads in one direction. Spindle bearings are available with a 15 degree degree contact angle. Various cage options are available as well as the use of ceramic balls which allow for higher speed, lower friction and heat generation and a longer operating life.
Send Inquiry to This Supplier
