7008CTYNSULP4 Abec-7 Super Precision Spindle Bearings. Matched Set of Two Paisr

7008CTYNSULP4 Abec-7 Super Precision Spindle Bearings. Matched Set of Two Paisr thumbnail-1
7008CTYNSULP4 Abec-7 Super Precision Spindle Bearings. Matched Set of Two Paisr thumbnail-2
7008CTYNSULP4 Abec-7 Super Precision Spindle Bearings. Matched Set of Two Paisr thumbnail-3
7008CTYNSULP4 Abec-7 Super Precision Spindle Bearings. Matched Set of Two Paisr photo-1
7008CTYNSULP4 Abec-7 Super Precision Spindle Bearings. Matched Set of Two Paisr photo-2
7008CTYNSULP4 Abec-7 Super Precision Spindle Bearings. Matched Set of Two Paisr photo-3
US$ 100 - 1000 MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
MONTON
Place of Origin:
China
Model Number:
7008CTYNSULP4
Contact Supplier Request Quote Chat Now
Luoyang Monton Bearing Science & Technology Co.,ltd.
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name MONTON
Place of Origin China
Model Number 7008CTYNSULP4
Number of Row Single Row
Seals Type seals
Precision Rating P4
Outside Diameter 10, 1000
Bore Size 10, 1000

7008CTYNSULP4 Abec-7 Super Precision Spindle Bearings.

Matched Set of Two pcs (back toback,face to face type)


Angular contact ball bearings are able to support radial load and axial load. As single row angular contact ball bearings can only support axial load in single direction, it often adopts mounting in pair. As matched pairs of bearings, preload for them is more convenient. Retainer are made of brass, synthetic resins or others subject to individual bearing feature and application conditions.

The raceways of angular contact ball bearing in the inner and outer rings can have relative displacement on the horizontal axis. Therefore, this design can make it withstand combined loads, namely, supporting radial and axial loads simultaneously. The axial load capacity of angular contact ball bearing improves with the increasing contact angle.


7008CTYNSULP4 SUPER PRECISION ANGULAR CONTACT SPINDLE BEARINGS

Brand : Monton

Type :Angular Contact Ball Bearings

Contact angle C: 15 Degree

Cage material TYN: Ball guided polyamide Resin

Rings material Bearing steel (SUJ2)

Rolling elements material Bearing steel (SUJ2)

Arrangement SU: universal Single row for matched set

Accuracy rating P4: ISO Class 4 (ABEC – 7)

Limiting speeds Grease: 21,300 rpm Oil: 32,500 rpm

Dynamic load rating 20.6 KN

Static load rating 15.9 KN

Axial load rating 10.6 KN

Dimensions 40mm x 68mm x 15mm

Quantity Two bearings

Made in China


THIS MATCHED SET OF TWO NSK 7008CTYNSULP4: REPLACES THE FOLLOWING

NSK 7008CTYNDBLP4 NSK 7008CTRDULP4Y NSK 7008CTRDULP4

NACHI 7008CYDUP4 NACHI 7008CYDU/GLP4

FAG7008 CT P4S DUL

SKF 7008CD/P4A SKF 7008CD/P4A DBA

FAFNIR 2MM9108WI DUL

BARDEN 108HDL

RHP 7008CTDULP4



Commodity name  super precision bearing angular contact ball bearing
Bearing model 7008CTYNSULP4 7008CTYNDBLP5 7008CTYNDULP4
Bearing specification 40*68*15 mm bearing
Weight /KG 0.189 KG
Greese/Oil As you requirement ,such as SRL,PS2,Alvania R12 and so on
Bearing Series 7xxx,B7xxx,Q,QJ,QJF,719xx,32xx,33xx,
Ring Materical Chrome Steel,Carbon steel, Stainless steel
Tolerance grade GB/T307.1-205
ID Size 10mm-280mm
Quality standard NSK precision bearing passed ISO 9001:2008 standard
Bearing Precision P0,P6,P5 ,P4
Steel pressed cage Bending claw form or rivet form
Delivert Date Normally ready goods and stock within 7 days
Payment Terms A:30% T/T In Advance,70% Against Copy Of B/L B: 100% L/C At Sight C: Paypal D: Western Union
Application Home appliances, low noise and high speed electric motors,automotive
components,pumps,machinery.
Bearing Service  precision bearing can offer OEM service
Package Single box or according to buyers requirement


Angular Contact Ball Bearing Specification:


Seals Types 2RS,OPEN
Vibration Level Z1V1,Z2V2,Z3V3
Clearance C2,C0,C3,C4,C5
Tolerance Codes ABEC-1,ABEC-3,ABEC-5
Materral GCr15-China/AISI52100-USA/Din100Cr6-Germany
MOQ 1Set at least
Delivery Time 15-45 days after contract
Payment Terms TT/PAPAL/WESTERN UNION
Pavkage Tube package+outer carton+pallets;Single box+outer carton+pallets;Tube pavkge+middle box+outer carton+pallets;According to your requirement


Angular contact ball bearing Models and Size:

(r/min)





Principal dimensions

Speed ratings
Basic load ratings
(kg)
Bearing NO. d D B

(kN) (kN) Mass




Grease Oil Dynamic Static
7000AC 10 26 8 19000 28000 4.75 2.12 0.018
7000C 10 26 8 19000 28000 4.92 2.25 0.018
7001AC 12 28 8 18000 26000 5.2 2.55 0.02
7001C 12 28 8 18000 26000 5.42 2.65 0.02
7002AC 15 32 9 17000 24000 5.95 3.25 0.028
7002C 15 32 9 17000 24000 6.25 3.42 0.028
7003AC 17 35 10 16000 22000 6.3 3.68 0.036
7003C 17 35 10 16000 22000 6.6 3.85 0.036
7004AC 20 42 12 14000 19000 10 5.78 0.064
7004C 20 42 12 14000 19000 10.5 6.08 0.064
7005AC 25 47 12 12000 17000 11.2 7.08 0.074
7005C 25 47 12 12000 17000 11.5 7.45 0.074
7006AC 30 55 13 9500 14000 14.5 9.85 0.11
7006C 30 55 13 9500 14000 15.2 10.2 0.11
7007AC 35 62 14 8500 12000 18.5 13.5 0.15
7008AC 40 68 15 15000 21000 16 12.9 0.21
7009C 45 75 16 14000 19000 19.87 16.36 0.24
7009AC 45 75 16 14000 19000 19.87 16.36 0.24
7010C 50 80 16 13000 17000 21 19 0.26
7010AC 50 80 16 13000 17000 21 19 0.26
7011C 55 90 18 12000 15000 26.1 22.6 0.36
7011AC 55 90 18 12000 15000 26.1 22.6 0.36
7012C 60 95 18 11000 14000 32.5 27 0.45
7012AC 60 95 18 11000 14000 32.5 27 0.45
7013C 65 100 18 9900 13000 35.2 30 0.5
7013AC 65 100 18 9900 13000 35.2 30 0.5
7014C 70 110 20 9200 12000 41.1 37.3 0.59
7014AC 70 110 20 9200 12000 41.1 37.3 0.59
7015C 75 115 20 8600 11000 42.5 40.7 0.69
7015AC 75 115 20 8600 11000 42.5 40.7 0.69




(r/min)




Principal dimensions

Speed ratings
Basic load ratings
(kg)
Bearing NO. d D B

(kN) (kN) Mass




Grease Oil Dynamic Static
7016C 80 125 22 8000 11000 53.4 50.6 0.93
7016AC 80 125 22 8000 11000 53.4 50.6 0.93
7017C 85 130 22 7600 10000 54.6 53.7 0.95
7017AC 85 130 22 7600 10000 54.6 53.7 0.95
7018C 90 140 24 7100 9500 68.6 65.4 0.96
7018AC 90 140 24 7100 9500 68.6 65.4 0.96
7019C 95 145 24 6800 9000 73.5 73 1.17
7019AC 95 145 24 6800 9000 73.5 73 1.17
7020C 100 150 24 6400 8600 75.5 77 1.25
7020AC 100 150 24 6400 8600 75.5 77 1.25
7021C 105 160 26 6100 8100 88 89.5 1.53
7021AC 105 160 26 6100 8100 88 89.5 1.53
7022C 110 170 28 5800 7700 101 101 1.91
7022AC 110 170 28 5800 7700 101 101 1.91
7024C 120 180 28 5300 7100 103 108 2.04
7024AC 120 180 28 5300 7100 103 108 2.04
7026C 130 200 33 4900 6500 129 137 3.73
7026AC 130 200 33 4900 6500 129 137 3.73
7028C 140 210 33 4500 6000 132 145 3.96
7028AC 140 210 33 4500 6000 132 145 3.96
7030C 150 225 35 4200 5600 151 168 4.82
7030AC 150 225 35 4200 5600 151 168 4.82
7200AC 10 30 9 18000 26000 5.58 2.82 0.03
7200C 10 30 9 18000 26000 5.82 2.95 0.03
7201AC 12 32 10 17000 24000 7.1 3.35 0.035
7201C 12 32 10 17000 24000 7.35 3.52 0.035
7202AC 15 35 11 16000 22000 8.35 4.4 0.043
7202C 15 35 11 16000 22000 8.68 4.62 0.043
7203AC 17 40 12 15000 20000 10.5 5.65 0.062
7203C 17 40 12 15000 20000 10.8 5.95 0.062




(r/min)




Principal dimensions

Speed ratings
Basic load ratings
(kg)
Bearing NO. d D B

(kN) (kN) Mass




Grease Oil Dynamic Static
7204C 20 47 14 25000 34000 15 8.6 0.1
7204AC 20 47 14 25000 34000 15 8.6 0.1
7204B 20 47 14 25000 34000 13.31 7.65 0.12
7205C 25 52 15 21000 28000 16.2 10.3 0.13
7205AC 25 52 15 21000 28000 16.2 10.3 0.13
7205B 25 52 15 21000 28000 14.03 8.63 0.14
7206C 30 62 16 18000 24000 16.94 12.14 0.2
7210C 50 90 20 12000 15000 32.91 26.83 0.45
7210AC 50 90 20 12000 15000 32.91 26.83 0.45
7211AC 55 100 21 11000 14000 40.71 33.96 0.6
7212AC 60 110 22 9700 13000 46.9 40.53 0.81
7213AC 65 120 23 9000 12000 53.67 46.22 1.01
7214AC 70 125 24 8300 11000 56.04 49.52 1.08
7215AC 75 130 25 7800 10000 60.91 54.34 1.68
7216AC 80 140 26 7300 9700 68.81 63.35 1.48
7217AC 85 150 28 6900 9100 77.5 72.6 1.88
7218AC 90 160 30 6500 8600 89.91 82.6 2.26
7219AC 95 170 32 6100 8100 96.5 88.8 2.78
7220AC 100 180 34 5800 7700 111.2 96.8 3.32
7221AC 105 190 36 5500 7300 119.2 105.6 3.95
7222AC 110 200 38 5200 6900 129.6 118.4 4.65
7224AC 120 215 40 4800 6400 139.2 132.8 5.49
7226AC 130 230 40 4400 5800 156.8 156.8 6.21
7228AC 140 250 42 4000 5300 174.4 187.2 7.76
7230AC 150 270 45 3700 5000 248 280 9.75
7232AC 160 290 48 2400 2600 230 263 12.1
7234AC 170 310 52 2400 2400 272 331 15.1
7236AC 180 320 52 2200 2400 303 390 18.1
7238AC 190 340 55 2000 2200 303 390 18.8
7240AC 200 360 59 1800 2000 324 423 22.4
