7006CTYNDBLP4 30x55x13mm Precision Angular Contact ball bearings for precision pcb board machine
High precision angular contact ball bearing with phenolic cage, 15 degree contact angle 30mm inside x 55mm outside x 13mm wide
High Precision Angular Contact Ball Bearings (standard series) have a line connecting the contact points drawn in the radial direction which is called the contact angle. This contact angle makes the bearing suitable for accommodating radial loads, single direction axial loads and a combination of both, these bearings are generally used in pairs but can also be used in triplex sets, quadruplex sets or multiplex sets,
70xx, 72xx and 79xx series have three types of contact angle 15 degree (C), 25 degree (A5) and 30 degree (A), all come with two types of cage design either phenolic (TR) or polyamide (TYN),
d: 30mm
D: 55mm
B: 13mm
Basic load ratings: dynamic 15.9kn, static 10.3kn
Permissible axial load: 6.85kn
Contact angle (degree) 15
Factor: 14.9fo
Effective load center: 12.2mm
Mass:
Limiting speed grease: 27 100
Limiting speed oil: 41 200
| Product Name: | 7006CTYNDBLP4 angular contact ball bearings: | ||
| Bearing Size: | 30X55X13mm (d*D*B) | ||
| Weight: | contact me | ||
| Seal type: | Open,metallic seal,Rubber seal | ||
| Precision: | p5 p4 p3 p2 | ||
| cage material: | Bakelite,Brass,Nylon | ||
| Number of row | Single Row | ||
| Port: | Qingdao or Guangzhou | ||
| Delivery time: | 1-7days,According to QTY | ||
