Home > Industrial Equipment & Components > Bearing > Angular Contact Ball Bearing > 71826 CDGA / P4A Ball Bearing Angular Contact , Single Row Spindle Bearing
71826 CDGA / P4A Ball Bearing Angular Contact , Single Row Spindle Bearing
US$ 15 - 100
MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
monton
Place of Origin:
China
Model Number:
7004C/AC DBL P4
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or Beijing
Delivery Detail:
1 days
Related Products
-
7010 AC P4 Angular Contact Bearings , High Precision Spindle Bearing High SppedUS$ 15 - 100MOQ: 1 Piece -
Spindle Bearings List-old and New DesignationsUS$ 15 - 100MOQ: 1 Piece
-
7001B 12X28X8mm Full Ceramic Angular Contact Ball BearingsUS$ 15 - 100MOQ: 1 Piece
-
7002CTRDULP4 7002 CTGA P4 Super Precision Angular Contact Bearing 15x32x9mmUS$ 15 - 100MOQ: 1 Piece
-
60TAC120BSUC10PN7B Ball Screw Support Bearing 60x120x20mm/ High Precision Spindle BearingsUS$ 15 - 100MOQ: 1 Piece
Brand Name
monton
Place of Origin
China
Model Number
7004C/AC DBL P4
Number of Row
Single Row
Seals Type
open or sealed
Precision Rating
50000r/min
Outside Diameter
10, 300
Bore Size
5, 200
71826 CDGA/P4A Angular Contact Ball Bearing Spindle Bearing
71826 CDGA/P4A Bearing Specification :
| Model Number | 71826 CDGA/P4A |
| Part Name | Angular Contact Ball Bearing |
| Row | Single Row |
| Dimensions(mm)(d*D*b) | 130mm X 165mm X 18mm |
| Weight / Mass ( KG ) | 0.782kg |
| Precision Rating | ABEC-7/ P4 |
| Brand | Monton |
| Original Country Show | CHINA |
Same Series Bearings
| Bearing No. | Size | Basic Load | Limited Speed | Mass | ||||
| d | D | B | Cr | Cor | Grease | ≈ | ||
| mm | KN | r/min | kg | |||||
| 71803CD/P4A Bearing | 17 | 26 | 5 | 2.3 | 1.9 | 53000 | 80000 | 0.008 |
| 71803CDGA/P4A Bearing | ||||||||
| 71803CDGB/P4A Bearing | ||||||||
| 71803CDGC/P4A Bearing | ||||||||
| 71803ACD/P4 Bearing | 17 | 26 | 5 | 2.1 | 1.8 | 50000 | 75000 | 0.008 |
| 71803ACDGA/P4A Bearing | ||||||||
| 71803ACDGB/P4A Bearing | ||||||||
| 71803ACDGC/P4A Bearing | ||||||||
| 71804CD/P4A Bearing | 20 | 32 | 7 | 3.9 | 3.4 | 45000 | 67000 | 0.018 |
| 71804CDGA/P4A Bearing | ||||||||
| 71804CDGB/P4A Bearing | ||||||||
| 71804CDGCP4A Bearing | ||||||||
| 71804ACD/P4A Bearing | 20 | 32 | 7 | 3.7 | 3.2 | 40000 | 60000 | 0.018 |
| 71804ACDGA/P4A Bearing | ||||||||
| 71804ACDGB/P4A Bearing | ||||||||
| 71804ACDGC/P4A Bearing | ||||||||
| 71805CD/P4A Bearing | 25 | 37 | 7 | 4.2 | 4.1 | 38000 | 56000 | 0.022 |
| 71805CD/P4A Bearing | ||||||||
| 71805CD/P4A Bearing | ||||||||
| 71805CD/P4A Bearing | ||||||||
| 71805ACD/P4A Bearing | 25 | 37 | 7 | 3.9 | 3.9 | 34000 | 50000 | 0.022 |
| 71805ACDGA/P4A Bearing | ||||||||
| 71805ACDGB/P4A Bearing | ||||||||
| 71805ACDGC/P4A Bearing | ||||||||
| 71806CD/P4A Bearing | 30 | 42 | 7 | 4.4 | 4.8 | 32000 | 48000 | 0.025 |
| 71806CDGA/P4A Bearing | ||||||||
| 71806CDGB/P4A Bearing | ||||||||
| 71806CDGC/P4A Bearing | ||||||||
| 71806ACD/P4A Bearing | 30 | 42 | 7 | 4.1 | 4.5 | 28000 | 43000 | 0.025 |
| 71806ACDGA/P4A Bearing | ||||||||
| 71806ACDGB/P4A Bearing | ||||||||
| 71806ACDGC/P4A Bearing | ||||||||
| 71807CD/P4A Bearing | 35 | 47 | 7 | 4.6 | 5.5 | 26000 | 40000 | 0.029 |
| 71807CDGA/P4A Bearing | ||||||||
| 71807CDGB/P4A Bearing | ||||||||
| 71807CDGC/P4A Bearing | ||||||||
| 71807ACD/P4A Bearing | 35 | 47 | 7 | 4.3 | 5.2 | 24000 | 38000 | 0.029 |
| 71807ACDGA/P4A Bearing | ||||||||
| 71807ACDGB/P4A Bearing | ||||||||
| 71807ACDGC/P4A Bearing | ||||||||
| 71808CD/P4A Bearing | 40 | 52 | 7 | 4.8 | 6.2 | 24000 | 38000 | 0.032 |
| 71808CDGA/P4A Bearing | ||||||||
| 71808CDGB/P4A Bearing | ||||||||
| 71808CDGC/P4A Bearing | ||||||||
| 71808ACD/P4A Bearing | 40 | 52 | 7 | 4.5 | 5.8 | 20000 | 34000 | 0.032 |
| 71808ACDGA/P4A Bearing | ||||||||
| 71808ACDGB/P4A Bearing | ||||||||
| 71808ACDGC/P4A Bearing | ||||||||
| 71809CD/P4A Bearing | 45 | 58 | 7 | 4.9 | 6.7 | 20000 | 34000 | 0.04 |
| 71809CDGA/P4A Bearing | ||||||||
| 71809CDGB/P4A Bearing | ||||||||
| 71809CDGC/P4A Bearing | ||||||||
