Help Center7002CTRDULP4 7002 CTGA P4 Super Precision Angular Contact Bearing 15x32x9mm
Related Products
-
60TAC120BSUC10PN7B Ball Screw Support Bearing 60x120x20mm/ High Precision Spindle BearingsUS$ 15 - 100MOQ: 1 Piece -
7006CTYNSULP4 7006C Precision Spindle Bearing Angular Contact Ball BearingUS$ 15 - 100MOQ: 1 Piece
-
HSS71900-C-T-P4S HSS71901-C-T-P4S HSS71902-C-T-P4S HSS 71903 High Precision Spindle Bearing Angular Contact BearingUS$ 15 - 100MOQ: 1 Piece
-
80BNC90/HC71916C.T.P4S Spindle BearingsUS$ 15 - 100MOQ: 1 Piece
-
Spindle Bearings 85BTR10ETYNDBLP4AUS$ 15 - 100MOQ: 1 Piece
High Precision Angular Contact Ball Bearings (standard series) have a line connecting the contact points drawn in the radial direction which is called the contact angle. This contact angle makes the bearing suitable for accommodating radial loads, single direction axial loads and a combination of both, these bearings are generally used in pairs but can also be used in triplex sets, quadruplex sets or multiplex sets,
70xx, 72xx and 79xx series have three types of contact angle 15 degree (C), 25 degree (A5) and 30 degree (A), all come with two types of cage design either phenolic (TR) or polyamide (TYN),
d: 15mm
D: 32mm
B: 9mm
Basic load ratings: dynamic 6.25kn, static 3.40kn
Permissible axial load: 2.63kn
Contact angle (degree) 15
Factor: 14.1fo
Effective load center: 7.6mm
Mass: 0.0030kg
Limiting speed grease: 49 000
Limiting speed oil: 74 500
Bearing accuracy class standard interchangeable table:
Standards |
Precision Grade |
||||
GB |
G |
E |
D |
C |
B |
ISO |
Normal Class |
Class 6 |
Class 5 |
Class 4 |
Class 2 |
ANSI |
ABEC-1 |
ABEC-3 |
ABEC-5 |
ABEC-7 |
ABEC-9 |
DIN |
P0 |
P6 |
P5 |
P4 |
P2 |
