7010 AC P4 Angular Contact Bearings , High Precision Spindle Bearing High Temp
Our angular contact bearing 7010 AC P4 product advantage:
Bearing external shage size tolerance guantee to +/-0.001mm,
Bearing rings Hardness HRC60~62,
We also could do customized size from our factory: Seller provide bearing finall production drawing for mutral confirmation.
Only after order confirmed,and seller received buyer deposit.
We using standard bearing steel for rings and roller, strict heat treatment for bearing inner rings and bearin external ring;
Using forged raw material for inner and outer rings.
G10 Grage balls, chrome steel Gcr15
We have steel cage and nylon material cage both available, steel cage is much more heavy,and nylon cage is much more light and more durable.
We using forging material for our bearing inner and outer rings.
The difference between forging and casting material:
Forging is formed by forging after the metal is heated in solid state. It requires the metal to have good thermoplastic (also known as forging), and the general forging is steel, which is of high strength and plasticity, which is suitable for high quality and high quality components. Such as bolts, shafts, gears, axle, etc.
The casting metal is formed in liquid casting and casting. It requires good fluidity, filling ability of liquid metal, etc. (also called casting), divided into two cast steel and cast iron in the iron and steel casting, iron carbon content is higher than steel, its low strength over steel, plastic, poor general tolerances for the production is not very big parts, such as machine tools, such as the low pressure valve; Steel casting strength is high, used for making complex parts, such as chain rail, high pressure valve seat, etc.
precision angular contact bearing 3306 2RS P5 Product specifications and parameter data
| bearing type | ISO bearing NO. | OLD bearing NO. | ID | OD | WIDTH | Cr | Cor | grease lubricatedx speed |
oil lubricated speed |
weight |
| motorcycle bearing | (mm) | (mm) | (mm) | (kN) | (kN) | (r/min) | (r/min) | (kg) | ||
| angular contact bearing | 7010C | 36110 | 50 | 80 | 16 | 26 | 21.9 | 13000 | 17000 | 0.29 |
| angular contact bearing | 7010AC | 46110 | 50 | 80 | 16 | 23.6 | 20.1 | 9200 | 11000 | 0.29 |
| angular contact bearing | 7010CTA | - | 50 | 80 | 16 | — | — | — | — | 0.26 |
| angular contact bearing | 7010CETA | - | 50 | 80 | 16 | — | — | — | — | 0.26 |
| angular contact bearing | 7010ACM | 46110H | 50 | 80 | 16 | — | — | — | — | 0.26 |
| angular contact bearing | B7010C/YA | - | 50 | 80 | 16 | — | — | — | — | 0.26 |
| angular contact bearing | 7010AC/DB | 246110 | 50 | 80 | 32 | 38.4 | 40.2 | 7300 | 9200 | 0.576 |
| angular contact bearing | 7010AC/DF | 346110 | 50 | 80 | 32 | 38.4 | 40.2 | 7300 | 9200 | 0.576 |
| angular contact bearing | 7010AC/DT | 446110 | 50 | 80 | 32 | 38.4 | 40.2 | 7300 | 9200 | 0.576 |
| angular contact bearing | 7010C/DB | 236110 | 50 | 80 | 32 | 42.2 | 43.9 | 10000 | 13000 | 0.576 |
| angular contact bearing | 7010C/DF | 336110 | 50 | 80 | 32 | 42.2 | 43.9 | 10000 | 13000 | 0.576 |
| angular contact bearing | 7010C/DT | 436110 | 50 | 80 | 32 | 42.2 | 43.9 | 10000 | 13000 | 0.576 |
| angular contact bearing | B7010C | 136110 | 50 | 80 | 16 | - | - | - | - | 0 |
| angular contact bearing | 7010ACJ | 46110F | 50 | 80 | 16 | - | - | - | - | 0.28 |
| angular contact bearing | 7010CJ | 36110F | 50 | 80 | 16 | - | - | - | - | 0.28 |
| angular contact bearing | 7010ACTA | 46110K | 50 | 80 | 16 | - | - | - | - | - |
| angular contact bearing | B7010-E-2RSD-T-P4S | B7010E.2RSD.T.P4S.UL | 50 | 80 | 16 | - | - | - | - | 0.266KG |
| angular contact bearing | 7010B | - | 50 | 80 | 16 | 21.2 | 18.1 | 6900 | 9200 | 0.29 |
| angular contact bearing | 7010B/DF | - | 50 | 80 | 32 | 34.5 | 36.2 | 5500 | 7400 | 0.595 |
| angular contact bearing | 7010B/DB | - | 50 | 80 | 32 | 34.5 | 36.2 | 5500 | 7400 | 0.595 |
| angular contact bearing | 7010B/DT | - | 50 | 80 | 32 | 34.5 | 36.2 | 5500 | 7400 | 0.595 |
