Technical Parameter of laboratory XMQ Cone ball Mill
XMQ Series Cone Ball Mill is a lab.grind equipmet for wet fine grinding of ore.It is applied in labs for processing and fine grinding of artifical placer materials and ores in metallurgical,building material,chemical,light,coal,water conservancy,electric power,agricultural and geological industries.The product is produced by the only enterprise designated by the former Ministry of Geology and Mineral Mineral Resources,in compliance with the Industrial standards
The experiment of grinding equipment, grinding time can be arbitrarily set, but also can be used in dry, wet grinding, using frequency conversion technology, speed range is wide, abrasive, mixing and even everything easy installation without foundation treatment, low noise, no dust pollution, to facilitate the work of cleaning, polishing sealing performance is good, ordinary ore optional experimental study and manual re-sanding of ore used in the rod mill more appropriate.
The grinding equipment, a large amount of feeding, discharging, cylinder power control, without manual, grinding time can be arbitrarily set
Model |
Uite |
XMQ150/50 |
XMQ240/90 |
XMQ350/160 |
Drum size |
mm |
150/50 |
240/90 |
350/160 |
Volume |
L |
1 |
6.25 |
21.58 |
Capacity |
g |
200 |
1000 |
4000 |
Feed size |
mm |
3 |
3 |
3 |
Rarticle size |
mm |
0.074 |
0.074 |
0.074 |
Drum speed |
r/min |
110-114 |
94-98 |
60-64 |
rower |
kw |
0.25 |
0.55 |
1.1 |
Overall dimensions |
mm |
915/530/1160 |
1050/640/1164 |
700/575/1190 |
Weighe |
kg |
91 |
170 |
300 |
