GWP Stainless steel vertical pipeline sewage pump is made of stainless steel material and used to transfer the dirty water containing solid particles or long fiber etc impurity or the clear water or corrosive liquids. GWP Stainless steel vertical pipeline sewage pump is convenient to install and can also be used as a general pipeline pump for booster supply water pump in high building. The pump adopts the unique single flow channel or double flow channel impeller and with a reasonable volute. The impeller has very good flow passage. So the pump has high efficiency, steady running and no vibration etc.
GWP Stainless steel pipeline not clogging sewage pump is widely used for wastewater discharge in industries, urban sewage treatment plants, sewage discharge in residential area, water system, civil air defense system drainage, waterworks water supply equipment, hospital, hotel, municipal engineering etc.
Environment temperature is less than 40 degree Celsius, humidity: not more than 95%, altitude: not higher than 1000m
Liquid temperature is less than 60 degree Celsius, density: 1 to 1.3kg/dm3
Liquid PH: 1-14
Stainless steel pump can be used for general alkali and corrosive liquids.
| Model | Inlet/outlet | Flow(m3/h) | Head(m) | Speed(RPM) | Power(KW) | Efficiency |
| (mm) | (%) | |||||
| 25GWP8-22-1.1 | 25 | 8 | 22 | 2825 | 1.1 | 38.1 |
| 32GWP12-15-1.1 | 32 | 12 | 15 | 2825 | 1.1 | 40 |
| 40GWP15-15-1.5 | 40 | 15 | 15 | 2840 | 1.5 | 45.1 |
| 40GWP15-30-2.2 | 40 | 15 | 30 | 2840 | 2.2 | 18 |
| 50GWP20-7-0.75 | 50 | 20 | 7 | 1390 | 0.75 | 54 |
| 50GWP10-10-0.75 | 50 | 10 | 10 | 1390 | 0.75 | 56 |
| 50GWP20-15-1.5 | 50 | 20 | 15 | 2840 | 1.5 | 55 |
| 50GWP15-25-2.2 | 50 | 15 | 25 | 2840 | 2.2 | 56 |
| 50GWP18-30-3 | 50 | 18 | 30 | 2880 | 3 | 58 |
| 50GWP25-32-5.5 | 50 | 25 | 32 | 2900 | 5.5 | 53 |
| 50GWP20-40-7.5 | 50 | 20 | 40 | 2900 | 7.5 | 55 |
| 65GWP25-15-2.2 | 65 | 25 | 15 | 2840 | 2.2 | 52 |
| 65GWP37-13-3 | 65 | 37 | 13 | 2880 | 3 | 55 |
| 65GWP25-30-4 | 65 | 25 | 30 | 2890 | 4 | 58 |
| 65GWP30-40-7.5 | 65 | 30 | 40 | 2900 | 7.5 | 56 |
| 65GWP35-50-11 | 65 | 35 | 50 | 2930 | 11 | 60 |
| 65GWP35-60-15 | 65 | 35 | 60 | 2930 | 15 | 63 |
| 80GWP40-7-2.2 | 80 | 40 | 7 | 1420 | 2.2 | 52 |
| 80GWP43-13-3 | 80 | 43 | 13 | 2880 | 3 | 50 |
| 80GWP40-15-4 | 80 | 40 | 15 | 2890 | 4 | 57 |
| 80GWP65-25-7.5 | 80 | 65 | 25 | 2900 | 7.5 | 56 |
| 100GWP80-10-4 | 100 | 80 | 10 | 1440 | 4 | 62 |
| 100GWP110-10-5.5 | 100 | 110 | 10 | 1440 | 5.5 | 66 |
| 100GWP100-15-7.5 | 100 | 100 | 15 | 1440 | 7.5 | 67 |
| 100GWP85-20-7.5 | 100 | 85 | 20 | 1400 | 7.5 | 68 |
| 100GWP100-25-11 | 100 | 100 | 25 | 1460 | 11 | 65 |
| 100GWP100-30-15 | 100 | 100 | 30 | 1470 | 15 | 66 |
| 100GWP100-35-18.5 | 100 | 100 | 35 | 1460 | 18.5 | 65 |
| 125GWP130-15-11 | 125 | 130 | 15 | 1460 | 11 | 62 |
| 125GWP130-25-15 | 125 | 130 | 20 | 1440 | 15 | 63 |
| 150GWP145-6-7.5 | 150 | 145 | 6 | 1470 | 7.5 | 63 |
| 150GWP180-15-15 | 150 | 180 | 15 | 1470 | 15 | 65 |
| 150GWP180-20-18.5 | 150 | 180 | 20 | 1470 | 18.5 | 75 |
| 150GWP180-25-22 | 150 | 180 | 25 | 1470 | 22 | 76 |
| 150GWP130-30-22 | 150 | 130 | 30 | 1470 | 22 | 75 |
| 150GWP180-30-30 | 150 | 180 | 30 | 970 | 30 | 73 |
| 150GWP200-30-37 | 150 | 200 | 30 | 970 | 37 | 70 |
| 200GWP300-7-11 | 200 | 300 | 7 | 1470 | 11 | 73 |
| 200GWP250-11-15 | 200 | 250 | 11 | 1470 | 15 | 74 |
| 200GWP400-10-22 | 200 | 400 | 10 | 1470 | 22 | 76 |
| 200GWP400-13-30 | 200 | 400 | 13 | 1470 | 30 | 73 |
| 200GWP250-11-15 | 200 | 250 | 15 | 1470 | 18.5 | 72 |
| 200GWP300-15-22 | 200 | 300 | 15 | 1470 | 22 | 73 |
| 200GWP250-22-30 | 200 | 250 | 22 | 1470 | 30 | 71 |
| 200GWP350-25-37 | 200 | 350 | 25 | 1470 | 37 | 75 |
| 200GWP400-30-55 | 200 | 400 | 30 | 1480 | 55 | 70 |
| 250GWP600-9-30 | 250 | 600 | 9 | 980 | 30 | 74 |
| 250GWP600-12-37 | 250 | 600 | 12 | 1480 | 37 | 78 |
| 250GWP600-15-45 | 250 | 600 | 15 | 1480 | 45 | 75 |
| 250GWP600-20-55 | 250 | 600 | 20 | 1480 | 55 | 73 |
| 250GWP600-25-75 | 250 | 600 | 25 | 1480 | 75 | 73 |
| 300GWP800-12-45 | 300 | 800 | 12 | 1480 | 45 | 76 |
| 300GWP500-15-45 | 300 | 500 | 15 | 980 | 45 | 70 |
| 300GWP800-15-55 | 300 | 800 | 15 | 980 | 55 | 73 |
| 300GWP600-20-55 | 300 | 600 | 20 | 980 | 55 | 75 |
| 300GWP800-20-75 | 300 | 800 | 20 | 980 | 75 | 78 |
| 300GWP950-20-90 | 300 | 950 | 20 | 980 | 90 | 80 |
| 300GWP1000-25-110 | 300 | 1000 | 25 | 980 | 110 | 82 |
| 300GWP1100-10-55 | 300 | 1100 | 10 | 980 | 55 | 84.5 |
| 350GWP1500-15-90 | 350 | 1500 | 15 | 980 | 90 | 83.1 |
| 350GWP1200-18-90 | 350 | 1200 | 18 | 980 | 90 | 83.2 |
| 350GWP1100-28-132 | 350 | 1100 | 28 | 740 | 132 | 78.5 |
| 350GWP1000-36-160 | 350 | 1000 | 36 | 740 | 160 | 82.1 |
