HYBRID STEP-SERVO MOTOR 23CF SERIES HIGH TORQUE LOW VIBRATION
General Specifications：
Step Angle ------------------------------------------------------1.8° (full step)
Step Angle Accuracy -------------------------------±5%(full step, no load)
Resistance Accuracy ----------------------------------------------------±10%
Inductance Accuracy ----------------------------------------------------±20%
Temperature Rise --------------80℃ Max(rated current, 2 phases on)
Ambient Temperature Range ---------------------------- -20℃∽+50℃
Insulation Resistance ---------------------------- 100MΩ Min. 500VDC
Dielectric Strength -------------------------500VAC 50Hz 1mA 1 Minute
Insulation Class ----------------------------------------------B Class (130℃)
ElectricalSpecifications:
Model |
L Motor Length (mm) |
Holding Torque (N.m) Min. |
Rated Voltage DC(V) |
Rated Current (A) |
Phase Resistance (Ω) |
Phase Inductance (mH) |
Rotor Inertia (kg.cm²) |
Motor Weight (kg) |
1000 Encoder | ||||||||
23CF5630-1000 |
73 |
1.0 |
24-48 |
3 |
0.7 |
1.2 |
0.26 |
0.6 |
23CF7630-1000 |
93 |
2.0 |
24-48 |
3 |
0.7 |
3.0 |
0.48 |
1.1 |
23CF11540-1000 |
129 |
3.0 |
24-48 |
4 |
1.0 |
3.6 |
0.88 |
1.5 |
Shown in the table is the representative product. It can be customized according to the requirements of users.
