B71821AC/P4DBB Super Precision Angular Contact Ball Bearing Single Row Spindle Bearing
US$ 15 - 100
MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
monton
Place of Origin:
China
Model Number:
B71821AC/P4DBB
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or Beijing
Delivery Detail:
1 days
Related Products
-
7215ACP4DBB 7215ACP5DBB Angular Contact Ball Bearing 75X130X25 High Precision Nylon CageUS$ 15 - 100MOQ: 1 Piece -
7207ACP4/DBB Angular Contact Ball Bearing 7207AC 46207 Radial Axial Bearing Single RowUS$ 15 - 100MOQ: 1 Piece
-
7026ACP5 Brass Cage Combined Angular Contact Ball Bearing With High SpeedUS$ 15 - 100MOQ: 1 Piece
-
71816CP5 Thin Wall High Speed Angular Contact Ball Bearing Spindle Bearing for Machine ToolUS$ 15 - 100MOQ: 1 Piece
-
7004CTRDULP4Y With 15° Contact Angle Super Precision Angular Contact Ball Bearing for Machine Tool SpindleUS$ 15 - 100MOQ: 1 Piece
Brand Name
monton
Place of Origin
China
Model Number
B71821AC/P4DBB
Number of Row
Single Row
Seals Type
open or sealed
Precision Rating
50000r/min
Outside Diameter
10, 300
Bore Size
5, 200
Description & Applicaitons
1) Machine tools and other precision applications require superior bearing performance. Extended speed capability, a high degree of running accuracy, high system rigidity, low heat generation, as well as low noise and vibration levels are just some of the challenges.
2) Rolling bearings for general industrial applications can only partly fulfill these requirements. Therefore, We manufacture a comprehensive assortment of super-precision bearings. Theses super-precision bearings help original equipment manufacturers and end users to further optimize performance parameters of their equipment and applications.
3) The benefits differ depending on the bearing series and applications but include high speed and load carrying ability, long bearing service life, long maintenance intervals and low energy consumption.
Typical applications for super-precision bearings are:
metal cutting and woodworking machinery spindles
other machine spindles (e.g. balancing machines)
high speed rolling mills
printing machinery
precision ball screws
live centres
high speed turbochargers
vacuum pumps
racing cars
boat gyrostabilizers
machine components for the semiconductor industry
Features:
superior bearing performance
extended speed capability
high degree of running accuracy
high system rigidity
low heat generation
low noise and vibration levels
Specifications:
| high precision contact ball bearing B71821 | |
| Model Number | B71821 |
| Structure | Angular Contact |
| Type | Ball |
| Brand Name | MOnton |
| Bore Size | 105mm |
| Outside Diameter | 130mm |
| Thickness | 13mm |
| Net weight | 0.4kg |
| Seals Type | Z, ZZ, RS, 2RZ, 2RS |
| Number of Row | Single Row |
| Place of Origin | Janpan |
| Material | Chrome steel, Stainless steel |
| Cage | Brass, Steel, Nylon |
| Vibration Level | V1, V2, V3 |
| Clearance | C0, C1, C2, C3, C4, C5 etc. |
| Precision Rating | P0, P6, P5, P4, P2 |
| Hardness | 59-63HRC |
| Service | OEM or original brand |
| Sample available | Yes |
| Manufacturer | Yes |
| Quality guaranteed | Yes |
| Certificate | ISO9001:2008, ISO/TS16949 |
| Application/Function | Automotive, truck, tractors, construction machinery |
| Other Service | Design service, Buyer label service |
| Packaging Details | Industrial Packing, Individual Boxed Packing, or OEM |
| Delivery Detail | 2-7 days after receiving the payments or deposit |
Competitive Advantage:
1. Quality level: reach the same level as the Japanese and European bearings
2. Tolerance level: ABEC-1 (P0), ABEC-3 (P6)
3. Less coefficient of friction
4. High limiting speed
5. Large size range
6. variations of structure
Related Model:
| Model # | d | D | w | Cr | Cor | |||
| (mm) | (mm) | (mm) | (kN) | (kN) | (r/min) | (r/min) | (kg) | |
| S7195J | 5 | 13 | 4 | 0.45 | 0.42 | 32000 | 43000 | 0.0023 |
| S7196J | 6 | 15 | 5 | 1.1 | 0.92 | 30000 | 40000 | 0.0039 |
| 71952Q4/YA | 260 | 360 | 46 | — | — | — | — | 12.9 |
| 71900CTA | 10 | 22 | 6 | — | — | — | — | 14.7 |
| 71901CTA | 12 | 24 | 6 | — | — | — | — | 14.7 |
| 71902CTA | 15 | 28 | 7 | — | — | — | — | 0.016 |
| 71903CTA | 17 | 30 | 7 | — | — | — | — | 0.017 |
| 71904CTA | 20 | 37 | 9 | — | — | — | — | 0.035 |
| 71905CTA | 25 | 42 | 9 | — | — | — | — | 0.035 |
| 71906CTA | 30 | 47 | 9 | — | — | — | — | 0.047 |
| 71907CTA | 35 | 55 | 10 | — | — | — | — | 0.075 |
| 71908CTA | 40 | 62 | 12 | — | — | — | — | 0.111 |
| 71909CTA | 45 | 68 | 12 | — | — | — | — | 0.126 |
| 71910CTA | 50 | 72 | 12 | — | — | — | — | 0.129 |
| 71911CTA | 55 | 80 | 13 | — | — | — | — | 0.174 |
| 71912CTA | 60 | 85 | 13 | — | — | — | — | 0.187 |
| 71913CTA | 65 | 90 | 13 | — | — | — | — | 0.2 |
| 71914CTA | 70 | 100 | 16 | — | — | — | — | 0.34 |
| 71915CTA | 75 | 105 | 16 | — | — | — | — | 0.36 |
| 71916CTA | 80 | 110 | 16 | — | — | — | — | 0.38 |
| 71917CTA | 85 | 120 | 16 | — | — | — | — | 0.53 |
| 71918CTA | 90 | 125 | 18 | — | — | — | — | 0.56 |
| 71919CTA | 95 | 130 | 18 | — | — | — | — | 0.582 |
| 71920CTA | 100 | 140 | 20 | — | — | — | — | 0.79 |
| 71922CTA | 110 | 150 | 20 | — | — | — | — | 0.821 |
| 71924CTA | 120 | 165 | 22 | — | — | — | — | 0.821 |
| 71926CTA | 130 | 180 | 24 | — | — | — | — | 1.52 |
| 71928CTA | 140 | 190 | 24 | — | — | — | — | 1.61 |
| 71930CTA | 150 | 210 | 28 | — | — | — | — | 1.61 |
| 71932CTA | 160 | 220 | 28 | — | — | — | — | 2.59 |
| 71934CTA | 170 | 230 | 28 | — | — | — | — | 2.77 |
| 71936CTA | 180 | 250 | 33 | — | — | — | — | 4.2 |
| 71938CTA | 190 | 260 | 33 | — | — | — | — | 6.02 |
| 71940CTA | 200 | 280 | 38 | — | — | — | — | 6.02 |
| 71900AC | 10 | 22 | 6 | - | - | - | - | - |
| 71900C | 10 | 22 | 6 | 3 | 1.5 | 52000 | 69000 | 0.008 |
| 71900C/DB | 10 | 22 | 12 | - | - | - | - | - |
| 71900C/DF | 10 | 22 | 12 | 4.9 | 3.05 | 42000 | 55000 | 0.016 |
| 71900C/DT | 10 | 22 | 12 | 4.9 | 3.05 | 42000 | 55000 | 0.016 |
| 71901AC | 12 | 24 | 6 | - | - | - | - | - |
| 71901C | 12 | 24 | 6 | - | - | - | - | - |
| 71901C/DB | 12 | 24 | 12 | 5.15 | 3.45 | 37000 | 49000 | 0.02 |
| 71901C/DF | 12 | 24 | 12 | 5.15 | 3.45 | 37000 | 49000 | 0.02 |
| 71901C/DT | 12 | 24 | 12 | 5.15 | 3.45 | 37000 | 49000 | 0.02 |
| 71902AC | 15 | 28 | 7 | - | - | - | - | - |
| 71902C | 15 | 28 | 7 | 4.75 | 2.65 | 39000 | 52000 | 0.015 |
