Product characteristics of [Lithium battery drop testing machine]
1. The device is provided with an electric control drop and a motor lifting device;
2. Single arm structure;
3. It can be customized according to the customer's needs.
Brief introduction of [Lithium battery drop testing machine]
The 7212A drop tester is used to test the damage caused by the fall of mobile phone, cell phone battery and other products, and to evaluate the impact strength of transportation and handling. The machine can be used for free drop test on the surface, angle and edge of the sample. The machine adopts a single arm structure and has electronic control drop and motor lifting device. The machine can be used conveniently and greatly to improve the service life, stationarity and safety of the machine.
Technical parameters of [Lithium battery drop testing machine] (customizable)
1. Comply with the relevant provisions of the IEC62133-2012,GB31241-2012 standard;
2. Fall height: 300~1500mm (adjustable), digital display;
3. Drop table: 1000 x 1000 mm;
4. The maximum size of the test piece is 200 × 200 × 300 mm;
5. Sample fixation mode: single arm type;
6. Test method: face, edge, angle all-round drop;
7. Test load: 0? 18kg;
8. Power supply: 220 V + 10%, 50 Hz + 2 Hz,5A;
9. Use of environmental advice: rooms with ventilation and smoke exhaust piping.
Maintenance and regular maintenance of [Lithium battery drop testing machine]
Maintenance:
To prevent the occurrence of electric shock, do not lift the cover of the instrument. All parts inside the instrument need not be maintained by the user. If there is an abnormal condition in the instrument, please ask for maintenance from my laboratory. the attached lines and block diagrams are for reference only.
Regular maintenance:
At least once a year, the AC power supply and relevant accessories of input power line shall be carefully checked and checked to protect the safety of the user and the accuracy of the instrument....
For more information about products, please contact us and visit the company.
Address: Tianhui Road, Wisdom City, Tianhe District, Guangzhou
Tel: 86-20-37896688
Fax:86-20-37896699
Mobile phone: 86-13711272581,Miss Liu
