Online Multiparameter Water Quality Sonde ODO, UV254 COD,OIW, PH, Ammonium, Conductivity, Turbidity, Chlorophyll
US$ 8 - 8
MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
BroadSensor
Place of Origin:
China
Model Number:
BSM-2
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai, Ningbo
Delivery Detail:
10 days
Related Products
-
Online Turbidity Sensor, RS485 Output, NTU, Water Quality Monitoring Sensor, MLSS, SSUS$ 8 - 8MOQ: 1 Piece -
Online Turbidity Sensor, RS485 Output, Multi-parameter Sonde, NTUUS$ 8 - 8MOQ: 1 Piece
-
Online Optical DO Sensor One Sonde of Multiparameter Sensor, Temperature Compensation, RS485 OutputUS$ 8 - 8MOQ: 1 Piece
-
Online 4-electrode Conductivity Sensor, RS485, Water Quality Monitoring SensorUS$ 8 - 8MOQ: 1 Piece
-
BroadSensor Online Chlorophyll Sensor RS485 OutputUS$ 8 - 8MOQ: 1 Piece
Brand Name
BroadSensor
Place of Origin
China
Model Number
BSM-2
PN：BSM-2
BSM-2 is the 2nd generation Online Multiparameter Water Quality Sonde. BSM-2 is an instrument that collects water quality results. There are six different sensors at most and one wiper can plug into the sonde at the same time. Each sensor measures their parameter through optical, physical or electrochemical method. The sonde identifies the sensor Automatically.
Key Advantages:
• Universal platform, uniform 3.5mm audio connector.
• Up to 7 ports, each port accepts up to six of Broadsensor sensors and one wiper, recognizes them automatically.
• All sensors are digital, support RS485 and Modbus RTU, all calibration parameters are stored in each sensor.
• The sonde supports RS485 and Modbus RTU.
• The sonde supports low power mode, water leakage alarm.
• Independent structure design, one sensor leakage or broken will not infect other parts.
• IP68 class.
| Item | Technical Specification |
|---|---|
| Interface |
IP68 connector, RS-485, Modbus RTU protocol |
Temperature(operation) |
0~45℃ |
Temperature(storage) |
-10~50℃ |
Power |
12~24V DC |
Power consumption |
20~120mA@12V（Different sensors and wiper）
|
Leakage alarm |
Support |
Wiper |
Support |
Warranty |
1 year, except for consumable material
|
IP rating |
IP68, |
Materials |
316L and POM |
Flow rate |
|
Accuracy, range and response time
|
Refer to the digital sensor spec |
Lifetime* |
Refer to the digital sensor spec |
Maintenance and calibration frequency*
|
Refer to the digital sensor spec |
Note: *Field life and calibration frequency dependent on site conditions.
