TK6511 cnc horizontal boring milling Machine
Such cnc horizontal boring and milling machine has following features:
1. horizontal boring and milling machines are universal machine tools which can be adapted to machine casting, steel, and nonferrous word- places.
2. Operations include drilling, hole enlarging, boring, reaming, plane milling, spot facing, threading, and other machining processes.
3. CE Standard and CE Certificate;
Specifications |
Unit |
Parameter |
Spindle diameter |
mm |
110 |
Spindle end face diameter |
mm |
190 |
Spindle taper |
|
BT50 |
Spindle torque |
Nm |
362 |
Spindle max. thrust |
N |
18000 |
Spindle motor power |
kW |
15(direct drive) |
Spindle speed |
rpm |
20~1000 |
Max. diameter to be bored |
mm |
Ø240 |
Max. diameter to be drilled |
mm |
Ø50 |
Max. table load |
kgs |
5000 |
Table cross travel(X-axis) |
mm |
1400 |
Table longitudinal travel(Z-axis) |
mm |
700 |
Spindle box travel(Y-axis) |
mm |
900 |
Spindle axial travel(W-axis) |
mm |
600 |
X/Y/Z axis rapid speed |
mm/min |
5500 |
Work table size |
mm |
1200x900 |
T-slot width |
mm |
28 |
Rotary table |
|
4x90° manaul |
Work table load |
kgs |
5000 |
Positioning accuracy X/Y/Z axis |
mm |
0.038/0.038/0.032 |
Repeated positioning accuracy X/Y/Z axis |
mm |
0.020/0.020/0.018 |
Total power |
kVA |
30 |
Machine weight |
kgs |
10000 |
Machine size |
mm |
3500×4200×3100 |
S.N |
Name |
Note |
1 |
Foundation blocks |
1 set |
2 |
Foundation screws |
1 set |
3 |
Handle |
1 pc |
4 |
Wrenches |
1 set |
5 |
Manual |
1 set |
