TPX6111 horizontal boring machine/horizontal borer
TPX6216(Ø160mm) Floor-type Horizontal Boring Machine
1. TPX61 series digital readout horizontal boring and milling machines are universal machine tools which can be adapted to machine casting, steel, and nonferrous word- places.
2. Operations include drilling, hole enlarging, boring, reaming, plane milling, spot facing, threading, and other machining processes.
3. The faceplate slide can be fed radically, which enables the machine to bore large size holes, turning outside diameters, and grooving.
4. This series of machine can be used in the industries of energy, metallurgy, mining, machinery, military, etc it is a reliable choice for machining box- type part.
5. Spindle of better rigidity, stronger cutting force, higher efficiency.
7. Optical sensor available for higher table locating accuracy
8. DRO available for both X and Y axes;
9. Automatic tool loading and unloading available as optional with spindle of ISO7:24 at 50 taper;
Specifications | Unit | Parameter |
Spindle diameter | mm | Φ110 |
Spindle taper | MT | 6 |
Max, spindle torque | Nm | 1225 |
Max. spindle axial thrust | N | 12250 |
Steps of spindle speed |
| 22 |
Range of spindle speed | r/min | 8~1000 |
Power of main motor | kW | 7.5 |
Max. facing head torque | Nm | 1960 |
Facing head diameter | mm | Φ630 |
Range of facing head speed | r/min | 4~200 |
Speed step of facing head speed |
| 18 |
Table size | mm | 1100 x1000 |
Max. permissible load on table | kg | 2500 |
T- slot | mm | 22 |
Number of T-slot |
| 10 |
X- axis travel | mm | 1000 |
Y - axis travel | mm | 1000 |
Z - axis travel | mm | 1000 |
W- axis travel (Spindle travel) | mm | 600 |
U - axis travel (facing head spindle travel) |
| 180 |
B - axis work table rotary |
| 360 |
Min. distance between spindle center and table surface | mm | 0 |
Rapid travel (X/Y/Z/W) | mm/min | 2500 |
Range of feed per spindle revolution (X/Y/Z/W) | mm/rev | 0.04~6/0.01~1.88 |
Linear measurement accuracy | mm | 0.005 |
B - axis measurement accuracy |
| 0.001 |
Overall dimensions (L*W*H) | mm | 4900x2560x2850 |
Weight of machine | kg | 13500 |
S.N | Name | Remark |
1 | Rear column | 1 Set |
2 | Face heading plate | 1 Set |
3 | Tool holder for boring | 1 pc |
4 | Tool holder for milling | 1 pc |
5 | Operation tools | 1 Set |
6 | Automatic centralized lubrication system | 1 Set |
7 | Work light | 1 Set |
8 | Documents in English | 1 Set |
Pls send inquiry to me for optioanl accessories and other further information about such horizontal borer/horizontal boring machine.
