Help CenterFence Semi Trailer / Side Wall Trailer
US$ 6000 - 25000
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
YONGCHAO
Place of Origin:
China
Model Number:
FT004
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
20 days
Related Products
-
Factory 3/4 Axles 40ft Side Wall Semi Cargo Truck Fence Semi Trailer Lowbed Semi Fence TrailerUS$ 6000 - 25000MOQ: 1 Set -
Fence Trailer / Semi Trailer/side Wall Trailer/flat Bed TrailerUS$ 6000 - 25000MOQ: 1 Set
-
Fence Trailer / Semi Trailer/side Wall Trailer/flat Bed TrailerUS$ 6000 - 25000MOQ: 1 Set
-
Fence Semi Trailer / Side Wall TrailerUS$ 6000 - 25000MOQ: 1 Set
-
Made in China Gooseneck Low Platform Semi Low Flatbed Trailer Lowbed Truck Trailer for SaleUS$ 3000 - 22000MOQ: 1 Set
Brand Name
YONGCHAO
Place of Origin
China
Model Number
FT004
Material
Steel
Size
13000*2500*3380mm
Certification
Other, CCC/SGS/ISO9001
Type
Semi-Trailer
Max Payload
70T
| Dimension(L*W*H) | 13000*2500 (fence height 1600 / 1800 / 2000 / 2200mm) |
| Tare Weight | 7.5t |
| Loading Weight | 70t |
| Axle | 13T, 1-4 pcs, BPW or FUWA or Yonglitai or Huajin Brand |
| Leaf Spring | 90*13-10, 6/8 sets, FUWA / Funiu / Taiyue etc. |
| Suspension system | Mechanical Suspension / air suspension / single point suspension (Germany Type or America Type or Japan Type) |
| Main Beam | Material: Q345 Carbon Steel. Beam height: 500mm. Upper plate: 14mm, down: 16mm, middle: 6/8 mm |
| Side Beam | 14#/16# channel steel (Q235) |
| Cross member | 8#/10# channel steel (Q235) |
| Platform | 8#/10# channel steel (Q235) |
| Side wall height | 600mm/800mm/1000mm etc. |
| Front board | 1500mm |
| Tire | 12R22.5-18, 12units |
| Steel Rim | 9.00-22.5, 12Units |
| Tool Box | 1 Standard (equipped with 1 unit tyre spanner, 1 unit gudgeon sleeve and 1 unit cranking bar) |
| Traction Pin | 2"(50mm) or 3.5"(90mm) |
| Spare Wheel Bracket | 1 piece |
| Landing Gear | Standard 28Ton, JOST or FUWA etc. |
| Brake system | WABCO available. 4 sets T30/30+2 sets T30 chamber; Two 40L tanks, ABS Optional |
Characteristics:
1. It can carry all kinds of cargo, mainly for farm and logistics, such as agricultural products, light cargo, animals, vegetables, fruits etc.
2. It can be customized, give you the one most suitable.
3. The structure is simple and easy dismantling, reasonably designed for different goods, to meet the fully weight situation and reduce cost.
4. Material: mixed with light high strength steel to balance the strength, stiffness and toughness of the frame, make it stronger.
5. Straight type or gooseneck type optional. Try our best to lower the center of gravity, to make the truck more stable at high speeds, and to enable to load more cargo.
