Fence Semi Trailer / Side Wall Trailer

FOB Price

US$ 6000 - 25000 / Set

1 Set(Min. Order)

Port QINGDAO
Payment TermsT/T L/C PayPal Other
Delivery Detail20 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	YONGCHAO	Place of Origin	China
Model Number	FT003	Material	Steel
Size	1300025003380mm	Certification	Other, CCC/SGS/ISO9001
Type	Semi-Trailer	Max Payload	70T

Product Description

Dimension(LWH)	13000*2500 (fence height 1600 / 1800 / 2000 / 2200mm)
Tare Weight	7.5t
Loading Weight	70t
Axle	13T, 1-4 pcs, BPW or FUWA or Yonglitai or Huajin Brand
Leaf Spring	90*13-10, 6/8 sets, FUWA / Funiu / Taiyue etc.
Suspension system	Mechanical Suspension / air suspension / single point suspension (Germany Type or America Type or Japan Type)
Main Beam	Material: Q345 Carbon Steel. Beam height: 500mm. Upper plate: 14mm, down: 16mm, middle: 6/8 mm
Side Beam	14#/16# channel steel (Q235)
Cross member	8#/10# channel steel (Q235)
Platform	8#/10# channel steel (Q235)
Side wall height	600mm/800mm/1000mm etc.
Front board	1500mm
Tire	12R22.5-18, 12units
Steel Rim	9.00-22.5, 12Units
Tool Box	1 Standard (equipped with 1 unit tyre spanner, 1 unit gudgeon sleeve and 1 unit cranking bar)
Traction Pin	2"(50mm) or 3.5"(90mm)
Spare Wheel Bracket	1 piece
Landing Gear	Standard 28Ton, JOST or FUWA etc.
Brake system	WABCO available. 4 sets T30/30+2 sets T30 chamber; Two 40L tanks, ABS Optional

Characteristics:
1. It can carry all kinds of cargo, mainly for farm and logistics, such as agricultural products, light cargo, animals, vegetables, fruits etc.
2. It can be customized, give you the one most suitable.
3. The structure is simple and easy dismantling, reasonably designed for different goods, to meet the fully weight situation and reduce cost.
4. Material: mixed with light high strength steel to balance the strength, stiffness and toughness of the frame, make it stronger.
5. Straight type or gooseneck type optional. Try our best to lower the center of gravity, to make the truck more stable at high speeds, and to enable to load more cargo.
