Home > Transportation > Trailer > Truck Trailer > Made in China Gooseneck Low Platform Semi Low Flatbed Trailer Lowbed Truck Trailer for Sale
Made in China Gooseneck Low Platform Semi Low Flatbed Trailer Lowbed Truck Trailer for Sale
US$ 3000 - 22000
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
YONGCHAO
Place of Origin:
China
Model Number:
LBT002
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
20 days
Related Products
-
Made in China Gooseneck Low Platform Semi Low Flatbed Trailer Lowbed Truck Trailer for SaleUS$ 3000 - 22000MOQ: 1 Set -
Made in China Gooseneck Low Platform Semi Low Flatbed Trailer Lowbed Truck Trailer for SaleUS$ 3000 - 22000MOQ: 1 Set
-
Made in China Gooseneck Low Platform Semi Low Flatbed Trailer Lowbed Truck Trailer for SaleUS$ 3000 - 22000MOQ: 1 Set
-
Made in China Gooseneck Low Platform Semi Low Flatbed Trailer Lowbed Truck Trailer for SaleUS$ 3000 - 22000MOQ: 1 Set
-
Made in China Gooseneck Low Platform Semi Low Flatbed Trailer Lowbed Truck Trailer for SaleUS$ 3000 - 22000MOQ: 1 Set
Brand Name
YONGCHAO
Place of Origin
China
Model Number
LBT002
Material
Steel
Size
13000*3000*1100mm or customize
Certification
Other, CCC/ISO9001/SGS
Type
Semi-Trailer
Max Payload
100T
Contacts: Kathy Chen
Mobile : +86 13853078353
Telephone: +86 530 6226658
E-mail: tianchen725@gmail.com
Whatsapp: +86 13853078353
Wechat: trailer-kathy
| Overall Dimension(L*W*H) | 13000*3000*1100mm or customize |
| Tare Weight | 7t |
| Loading Weight | 60t – 70t |
| Axle | 13T, 1-4 pcs, BPW / FUWA / Yonglitai / Huajin etc. |
| Leaf Spring | 90*13-10, 6/8 sets, Funiu / Taiyue etc. |
| Suspension system | Mechanical Suspension / air suspension / single point suspension (Germany Type or America Type or Japan Type) |
| Main Beam | T700 Steel. beam height 520mm, upper plate 12mm, down plate 14mm, middle plate 10mm. |
| Side Beam | T700 Steel, beam height 230mm, upper plate 8mm, down plate is 8mm, middle plate is 6mm. |
| Cross member | “C” type & “T” type channel steel |
| Platform plate | Side 4# checker plate, middle 1.8# checker plate |
| Steel Rim | 9.00-22.5, 12 pcs |
| Tool Box | 1 spanner, 1 gudgeon sleeve and 1 cranking bar |
| Tire Type and quantity | 12R22.5-18, 12units |
| Steel Rim | 9.00-22.5, 12Units |
| Tool Box | 1 Standard (equipped with 1 unit tyre spanner, 1 unit gudgeon sleeve and 1 unit cranking bar) |
| Traction Pin | 2"(50mm) or 3.5"(90mm) |
| Spare Wheel Bracket | 1 piece |
| Landing Gear | Standard 28Ton, Single-Side Operation or Double-Side Operation, JOST / FUWA etc. |
| Brake system | WABCO RE 6 relay valve; T30/30+T30 chamber; two 40L air tanks, ABS Optional |
| Ladder | 1 pair, Mechanical or hydraulic type, width 800mm |
| Electrical system | 1. Voltage: 24V, LED lights 2. Tail lamp with turn signal, brake light & reflector, side lamp etc. 3. 7 ways (7 wire harness) |
| Painting | Complete chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paints |
| other | Can add Mid & Rear Side protection, the side beam hook |
Send Inquiry to This Supplier
Mrs. kathy
sales manager
Heze, Shandong, China
* Email
Want the best price?
Post an RFQ now!
Business Type
Manufacturer
Year Established
2010
Factory Size
50,000-100,000 square meters
Annual Export Value
US$10 Million - US$50 Million
