Help CenterSVW60 5 Axis Cnc Vertical Machining Center/cnc Vmc
Related Products
-
SVW120 5 Axis Cnc Vertical Machining Center From Dalian FactoryUS$ 100,000 - 500,000MOQ: 1 Set -
GDM Series Bridge Type Cnc Gantry Machining CenterUS$ 50,000 - 150,000MOQ: 1 Set
-
GDM1220 Cnc Double Column Gantry Machining CenterUS$ 50,000 - 150,000MOQ: 1 Set
-
S-V2222 3 Axis Cnc Gantry Vertical Machining CenterUS$ 100,000 - 500,000MOQ: 1 Set
-
S-V3017 3 Axis Cnc Gantry Machining CenterUS$ 100,000 - 500,000MOQ: 1 Set
Items unit |
SVW60 |
|
Table dia. |
mm |
ø 600 |
Max. workpiece dia. |
mm |
ø 800 |
Max. workpiece weight |
kg |
500 |
Spindle speed |
rpm |
10000 |
Spindle motor |
KW |
10/12 |
torque |
Nm |
60/80 |
Taper size |
- |
SK40 |
X/Y/Z rapid speed |
m/min |
60/48/48 |
X/Y/Z working speed |
mm/min |
20~10000 |
A-axis speed |
rpm |
90 |
C-axis speed |
rpm |
100 |
X/Y/Z-axis travel |
mm |
650/650/550 |
A-axis rotary range |
° |
±125 |
C-axis rotary range |
° |
n×360 |
X/Y/Z-axis positioning accuracy |
µm |
8 |
X/Y/Z-axis repeated positioning accuracy |
µm |
5 |
B/C-axis positioning accuracy |
’’ |
8 |
B/C-axis repeated positioning accuracy |
’’ |
5 |
Tool magazine |
pieces |
40 |
Max. tool length |
mm |
350 |
Max. tool dia. |
mm |
ø 95 |
Max. tool dia. |
mm |
ø 150 |
Max. tool weight |
kg |
25 |
CNC system |
Heidenhain iTNC530/Siemens 840Dsl |
|
Machine weight |
T |
12 |
S.N |
Item |
Maker |
Quantity |
1 |
CNC system- iTNC530 |
HEIDENHAIN Germany |
1 |
2 |
Electrical elements |
HEIDENHAIN Germany |
1 |
3 |
Servo motors |
Siemens Germany |
4 |
4 |
Electric-motor |
INNA Germany |
1 |
5 |
Bearings |
NSK Japan |
N |
6 |
Torque motor for A/C rotary table |
IDAM Germany |
2 |
7 |
Ball screws |
NSK Japan |
4 |
8 |
Linear guides |
Schneeberger Germany |
8 |
9 |
Grating scale and encoders |
HEIDENHAIN Germany |
6 |
10 |
Hydraulic system |
HAWE Germany |
1 |
11 |
Pneumatic system |
Rexroth Germany |
1 |
12 |
Tool magazine |
Taiwan |
1 |
13 |
Automatic workpiece measurement |
HEIDENHAIN Germany |
1 |
14 |
Chains |
Top maker in China |
1 |
15 |
chip removal |
Top maker in China |
1 |
16 |
Emulsion paper filter |
Top maker in China |
1 |
17 |
Water-cooling device |
Top maker in China |
1 |
18 |
Air-conditioner for Electrical cabinet |
Top maker in China |
1 |
19 |
Lubrication system |
Top maker in China |
1 |
Pls send inquiry to me for optioanl accessories and other further information about such 5 axis cnc vertical machining centers.
