MDH65 OKK 5 axis cnc horizontal machining center
- 100 Set / Sets per Month
- Dalian/Tianjing/Shanghai/Qingdao China
- T/T Credit Card
- Catalogue of linear way and box way cnc vertical machining center with atc
- VDL800/1000 linear way cnc vertical machining center
- VDL500/600 3 axis cnc vertical machining center
- VDL1000 linear way cnc vertical machining center
- VDL series cnc vertical machining center/cnc vmc
- VDF1500 sliding guide way cnc vertical machining center cnc
Product Details
Brand Name: | DALIAN | Place of Origin: | Liaoning, China | Model Number: | MDH65 horizontal machining center |
Type: | Horizontal | Certification: | CE; ISO9001:2008; GB/T19001:2008 | After-sales Service Provided: | Engineers available to service machinery overseas |
Warranty: | 12 months | Weight: | 18 tons | Dimension(L*W*H): | 3420x5450x2700mm |
Voltage: | Customer's Requirement | Condition: | New | Power(W): | 22kW |
Product Description
MDH65 cnc horizontal machining center
LMH-400 Double Exchanger CNC Horizontal Machining Center
1. MDH Series cnc horizontal machining center is the ideal machining center for producing box-type and irregular work pieces for automobile, shipbuilding, engine and general manufacturing industries.
2. The machine is a high-performance, high-reliability and high-precision product characterized by compact configuration and rapid response rates.
3. The spindle design makes it particularly suitable for heavy power cutting while the excellent ball screw and spindle cooling system provide superb capability for flexible manufacturing.
4. High-speed High-power Spindle;
5. Compact Configuration and Unrivaled rigidity;
6. High-speed ATC;
7. High-speed APC
8. CE Standard and CE Certificate;
Specifications | Unit | Parameter |
Table size | mm | 630×630 |
Table top to spindle center distance | mm | 80~980 |
Table center to spindle front-end distance | mm | 200~1100 |
Maximum table load | kg | 1300 |
Table indexing |
| 1°×360° |
Tool storage capacity |
| 40(OP:60/80/120/160) |
Time of tool change | s | 2(T-T),4.2(C-C) |
Maximum tool weight | kg | 25 |
Maximum tool diameter | mm | Φ115(Adjacent empty:Φ270) |
Maximum tool length | mm | 500 |
Table indexing time | S | 1.7 (90°) |
Coordinate travel (X/Y/Z) | mm | 1050/900/900 |
Fast moving speed | m/min | 45(OP:54) |
Spindle speed | rpm | 35-8000 (OP:35-12000) |
Spindle speed gears |
| 2(MS) |
Spindle internal taper |
| 7/24 No.50 |
Spindle diameter | mm | Φ100 |
knife handle form |
| JISB6339 50T |
Rivets form |
| MASI 45° |
change table amount |
| 2 |
Table change the time | s | 12 |
Positioning accuracy
| mm | X±0.0030 Y/Z±0.0030 |
Repeat positioning accuracy | mm | X±0.0015 Y/Z±0.0015 JIS |
Machine weight | kg | 18000 |
Machine covers an area of size | mm | 3420×5450 |
