Small Gap Bed Bench Lathe Machine CQ6230B Bench Lathe
- 1000 per Month
- T/T Credit Card
- CW6163E CW6180E CW61100E Large Heavy Duty Metal Lathe Machine Price
- CW61100L CW61125L Big Bore Heavy Duty Metal Lathe Machine
- Mini Lathe Machine Price CJ0618 Lathe
- Mini Lathe Machine CQ6230B/CQ6232B Bench Lathe Machine For Sale
- Gap Bed Lathe CA6150 CA6250 Metal Hobby Lathe Machine Price
- Mini Lathe Machine C6132 Small Metal Lathe Machines for Sale
Product Details
Brand Name: | Luzhong Machine | Place of Origin: | Shandong, China | Model Number: | CQ6230B CQ6232B |
After-sales Service Provided: | No overseas service provided | Condition: | New |
Product Description
Small Gap Bed Bench Lathe Machine CQ6230B Bench Lathe
Product main technical Specifications:
Specifications | CQ6230B | CQ6232B |
Max .Swing over bed | Φ300mm | Φ320mm |
Max .Swing over cross slide | Φ180mm | Φ198mm |
Max .Swing in gap | Φ430mm | Φ476mm |
Max. distance between center | 750/910/1000mm | 750/910/1000mm |
Spindle bore | Φ38mm | Φ38mm |
Taper of spindle bore | M.T.#5 | M.T.#5 |
Range of spindle speed | 65~1400rpm | 65~1810rpm |
Range of longitudinal feeds | 0.079~1.291mm/rev. | 0.079~1.291mm/rev. |
Range of cross feeds | 0.017~0.276mm/rev. | 0.017~0.276mm/rev. |
Range of metric threads | 0.4~7mm | 0.4~7mm |
Range of inch threads | 4~60TPI | 4~60TPI |
Max. size of tool shank | 16×16mm | 16×16mm |
Taper of tailstock bore | M.T.#3 | M.T.#3 |
Power of main motor | 1.1/1.5kw | 1.1/1.5kw |
Unitary packing size | 1680×750×1400mm | 1680×750×1400mm |
Asunder packing size | 1680×750×750mm | 1680×750×750mm |
Left stand packing size | 690×400×370mm | 690×400×370 mm |
Right stand packing size | 690×400×300 mm | 690×400×300 mm |
Gross weight | 430kg | 450kg |
Net weight | 480kg | 490kg |
Tengzhou Luzhong Machine Tool Co., Ltd. is a large-scale manufacturing enterprise with glorious chievement and long history .Founed in 1992 ,company covers an area of 30 thousand square meters, the construction covers area of 250 thousand square meters.
Our main products are : CNC Lathe Machine ,CNC Milling Machine ,Vertical Machining Center ,Lathe Machine ,Drilling Machine ,Milling Machine and others metal cutting machine tools .All the products above have passed CE ,ISO ,SGS ,TUV certificates .
1:How can I choose the most suitable machines ?
A: Please tell me your specifications ,we can choose the best model for you , or you can choose the exact model .
You can also send us the products drawing ,we will choose the most suitable machines for you .
2: What's your main products of your company?
A: We specialized in all kinds of machines ,such as CNC Lathe Machine ,CNC Milling Machine ,Vertical Machining Center ,Lathe Machines ,Drilling Machine ,Radial Drilling Machine ,Sawing Machine ,Shaper machine and so on .
3: Where is our factory located? How can I visit there?
A : Our factory is located in Tengzhou City ,Shandong Province,277500 China. You are warmly welcomed to visit us.
4. What is your trade terms?
A : FOB, CFR and CIF all acceptable.
5: What's the Payment Terms ?
A : T/T ,30% initial payment when order ,70% balance payment before shipment ;
Irrevocable LC at sight .
5: What's the MOQ?
A: 1 set .(Only some low cost machines will be more than 1 set )
