Lathe Machine CZ1224 CZ1237 China Mini Bench Lathe For Sale
The main performance characteristics:
1.Engineered from high grade castings
2.V way bed ways induction hardened and ground
3.Gap bed
4.Cross and longitudinal interlocking feed, enough safety
5.Inching switch for test running
6.Metric/Imperial threading available
7.Belt-driven headstock,low noise and easy operation
Product main technical parameters:
Specifications |
| CZ1224(CZ300) | CZ1237 (CZ300/1) |
Swing over bed | mm | 305 | 305 |
Swing over carriage | mm | 173 | 173 |
Swing over gap | mm | 440 | 440 |
Width of bed-way | mm | 182 | 182 |
Distance between centers | mm | 530 | 940 |
Spindle taper |
| MT5 | MT5 |
Spindle bore | mm | 36 | 36 |
Step of speed |
| 12 | 12 |
Range of speed | rpm | 50-1200 | 50~1200 |
Metric thread | mm | 15 kinds(0.25~7.5) | 15 kinds(0.25~7.5) |
Inch thread | T.P.I | 40 kinds(4~112T.P.I) | 40 kinds(4~112T.P.I) |
Range of feed amount | Mm/r | 0.12~0.42(0.0017’’~0.0165’’) | 0.12~0.42(0.0017’’~0.0165’’) |
Diameter of lead screw | mm | 22(7/8’’) | 22(7/8’’) |
Pitch of lead screw |
| 3mm or 8 T.P.I | 3mm or 8 T.P.I |
Saddle travel | mm | 510 | 810 |
Cross travel | mm | 150 | 150 |
Compound travel | mm | 90 | 85 |
Barrel travel | mm | 100 | 95 |
Barrel diameter | mm | 32 | 32 |
Taper of center | mm | MT3 | MT3 |
Motor power | Kw | 1.1 | 1.1 |
Motor for coolant system’s power | Kw | 0.04 | 0.04 |
Machine(L×W×H) | mm | 1420x750x650 | 1780x750x650 |
Stand (left)(L×W×H) | mm | 400x370x3700 | 400x370x3700 |
Stand (right)(L×W×H) | mm | 300x370x700 | 300x370x700 |
Machine | Kg | 365/415 | 385/435 |
Machine stand | Kg | 60/65 | 60/65 |
Machine Model: Lathe Machine CZ1224 CZ1237 China Mini Bench Lathe For Sale
Type of package: Plywood case
Packaging size: 1780x750x650CM(one set in one case)
N.W./G.W.: 385/435KGS
1.Tengzhou Luzhong Machine Tool Co.,Ltd. is a large professional manufacturer.
2.Our products includes machining center,CNC lathes,CNC milling machines,Lathe, drilling machines, milling machine etc.
3.Our market covers more than 50 countries and regions.
4.Our products are reliable,we have got many certifications, such as CE,ISO etc.
5.Our products are used in aerospace, military industry, agricultural machinery, oil equipment, marine equipment, marine equipment, automobile manufacturing, equipment, coal mines, power equipment etc
