VMC850 Seal Maker Cnc Machine CNC Milling Machining Center

VMC850 Seal Maker Cnc Machine CNC Milling Machining Center thumbnail-1
VMC850 Seal Maker Cnc Machine CNC Milling Machining Center thumbnail-2
VMC850 Seal Maker Cnc Machine CNC Milling Machining Center thumbnail-3
VMC850 Seal Maker Cnc Machine CNC Milling Machining Center thumbnail-4
VMC850 Seal Maker Cnc Machine CNC Milling Machining Center thumbnail-5
VMC850 Seal Maker Cnc Machine CNC Milling Machining Center thumbnail-6
VMC850 Seal Maker Cnc Machine CNC Milling Machining Center photo-1
VMC850 Seal Maker Cnc Machine CNC Milling Machining Center photo-2
VMC850 Seal Maker Cnc Machine CNC Milling Machining Center photo-3
VMC850 Seal Maker Cnc Machine CNC Milling Machining Center photo-4
VMC850 Seal Maker Cnc Machine CNC Milling Machining Center photo-5
VMC850 Seal Maker Cnc Machine CNC Milling Machining Center photo-6
US$ 24,000 - 38,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
HANKUI/HUNK/OEM
Place of Origin:
Shandong, China
Model Number:
VMC850L
Contact Supplier Request Quote Chat Now
Machining Center
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name HANKUI/HUNK/OEM
Place of Origin Shandong, China
Model Number VMC850L
Type Vertical
Certification ISO CE
After-sales Service Provided Engineers available to service machinery overseas
Warranty 12 Months
Weight 5800kg
Dimension(L*W*H) 2750*2400*2600mm
Voltage Customer's Requirement
Condition New
Power(W) 7.5kw
Product Description

VMC850 Seal Maker Cnc Machine CNC Milling Machining Center

Application:

1. The VMC is suitable for the mechanical processing and mold making.

2. And it can adapt to the processing requirement from rough machining to finish machining.

3. It can also finish many working procedures like milling,drilling,tapping,boring.etc.


1. Imported high speed and high precision spindle.
2. Standard tool magazine.
3. High strength resin sand casting.
4. C3 grade ball screw
5. Imported cylindle from Taiwan
6. NSK bearing imported from Japan
7. Automatic intermittent lubricate system
8. Fully enclosed cover
9. Fanuc, Simens, Mitsubishi, Syntec CNC control system
Technical Parameter
ITEM
Unit
VMC850L
VMC855L
VMC1050L
VMC1060L
Table size
mm
1000*500
1000*550
1100*450
1200*600
T slot
5-18*90
18*5
18*3
5-18x90
Load capacity
kg
500
500
550
800
X-axis travel
mm
800
800
1000
1000
Y-axis travel
mm
500
550
530
600
Z-axis travel
mm
500
550
550
600
Distance from Spindle center to column slide way
mm
550
595
595
650
Distance from Spindle
center to table
mm
150-650
120-670
190-750
120-720
Tool shank
BT40
BT40
BT40
BT40
Spindle servo motor power
kw
7.5
7.5
11
11
Max diameter of tool
mm
φ80/φ150
φ80/φ150
φ80/φ150
φ80/φ150
Max length of tool
mm
250
300
300
300
Max weight of tool
mm
8
8
8
8
X/Y -axis rapid moving speed
mm
48000
48000
36000
36000
Z-axis rapid moving speed
mm
48000
48000
36000
36000
Feed Rate
mm/min
1-10000
1-10000
1-10000
1-10000
Positioning accuracy
mm
±0.008
±0.008
±0.008
0.01
Repeated Positioning accuracy
mm
±0.002/300
±0.002/300
±0.002/300
0.003
Out dimension
mm
2.7*2.4*2.6
2.75*2.4*2.6
2.8*2.4*2.7
3*2.5*2.9
N.W.
kg
5500
5800
6100
6500
Certifications
Main Features
Our Service

Pre-Sales Service

* Inquiry and consulting support.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.

Packing & Delivery
Packaging
Size
As the detailed machine model
Weight
No more than 15T



Packaging Details
The normal package is wooden box/Steel frame. If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
Related Products
The main products are horizontal / vertical/ gantry machining center, flat / slant bed CNC tuning lathe, CNC vertical turning lathe etc. With superior equipment, advanced technology, detection devices, the imported parts from Taiwan, Japan, Germany etc., we can manufacture the high quality machine tools. And we also take over the metal products and spare parts machining in good quality.
