Top Quality DFGC-90 Aquatic Plant Harvester

Top Quality DFGC-90 Aquatic Plant Harvester photo-1
US$ 83,000 - 98,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Dongfang
Place of Origin:
Shandong, China
Model Number:
DFGC-90
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao or Tianjin
Delivery Detail:
Delivery time depends on order quantity.
Brand Name Dongfang
Place of Origin Shandong, China
Model Number DFGC-90





Top Quality DFGC-90 aquatic plant harvester offers an environmentally sound method of controlling excessive aquatic plant growth and nuisance vegetation in waterways of all sizes. These heavy duty work boats are highly efficient in the management of submerged, emergent and free floating aquatic vegetation.

Like an underwater lawn mower, a top quality aquatic plant harvester cuts the vegetation, collecting and storing the weeds on board. Aquatic plant harvesters are fitted with a pick up conveyor at the forward end of the machine, which can be lowered up to six feet deep to cut weeds. One horizontal and two vertical cutter bars sever the vegetation as the machine moves forward through the water, and, when the storage hold becomes full, the weed harvester returns to shore to unload.

Depending on the size of your lake, the type of your weeds, the percentage of weeds you would like to remove, and how quickly you would like to harvest them, we will work with you to design a fully customizable weed harvester to meet your exact needs.

 Top Quality DFGC-90 Aquatic Plant HarvesterTop Quality DFGC-90 Aquatic Plant Harvester

 DFGC-90 Aquatic Weed Harvester

Top Quality DFGC-90 Aquatic Plant Harvester

Item

Parameter

Notes

Length Overall

14.6m



Hull Length

8.8m



Hull Width

3.2m



Hull Depth

1.2m



Draft Designed

0.45m



Draft Loaded

0.65m



Max.Collecting Depth

2m



Max.Collecting Width

3.4m



Load Capacity

6-7.2m3



Traveling Speed

7-12km/hr



Working Speed

2-3km/hr



Endurance

24hr



Drive Mode

Bilateral Paddle Wheel



Max.Discharge Height

4m



Working Capacity

2000-3500m2/hr





Our Service

1.Customized design and pre-sale service.

2.Lifetime after-sale service.
3.On-site installation and worker training.
4.Provide wear parts in time.
