XY-100 Small Portable Hydraulic Rotary Water Well Drilling Rig For Sale

XY-100 Small Portable Hydraulic Rotary Water Well Drilling Rig For Sale thumbnail-1
XY-100 Small Portable Hydraulic Rotary Water Well Drilling Rig For Sale thumbnail-2
XY-100 Small Portable Hydraulic Rotary Water Well Drilling Rig For Sale thumbnail-3
XY-100 Small Portable Hydraulic Rotary Water Well Drilling Rig For Sale thumbnail-4
XY-100 Small Portable Hydraulic Rotary Water Well Drilling Rig For Sale thumbnail-5
XY-100 Small Portable Hydraulic Rotary Water Well Drilling Rig For Sale photo-1
XY-100 Small Portable Hydraulic Rotary Water Well Drilling Rig For Sale photo-2
XY-100 Small Portable Hydraulic Rotary Water Well Drilling Rig For Sale photo-3
XY-100 Small Portable Hydraulic Rotary Water Well Drilling Rig For Sale photo-4
XY-100 Small Portable Hydraulic Rotary Water Well Drilling Rig For Sale photo-5
US$ 1800 - 2100 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Huaxia Master
Place of Origin:
China
Model Number:
XY-100
Contact Supplier Request Quote Chat Now
Shandong Huaxia Master Machinery Group CO,. LTD
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name Huaxia Master
Place of Origin China
Model Number XY-100
Type Rotary Drilling Rig
Certification ISO9001
After-sales Service Provided Engineers available to service machinery overseas
Warranty 6 months
Weight 610kg
Dimension(L*W*H) 2.1*0.9*1.3 m
Power Type Diesel
Voltage 380v
Usage Water Well
Condition New
Power(W) 10kw

1. The applications of XY-100 water well drilling rig

XY-100 water well drilling rig is widely used for Water well drilling, Geological Exploration and Prospecting, Geothermal wells, Blast-hole, Irrigation projects, etc.

2. The specifications of XY-100 drilling rig

Drilling depth

110

Maximum open hole diameter

220mm

End hole diameter

75mm

Drilling pipe diameter

50mm/42mm

Drilling angle

90

Drilling rig weight (exclude diesel engine)

610kg

Dimension

2.1*0.9*1.3m

Spindle

Rotating speed

130/300/480/730/830/1045 r/min

Stroke

450mm

Winch

Maximum lifting force

1600kg

Lifting speed

1.06/0.67/0.32 m/s

Wire-rope diameter

13mm

Roll capacity

50m

Mud pump

Type

Horizontal single cylinder double acting

Displacement (with diesel engine/electric motor)

170l/min

Max. pressure

1.5mpa

Work pressure

0.7mpa

Power

Diesel engine

S1100

Electric motor

Y160M-4  10KW
