Filter bagarecomposedbywoven filter material bag body, snap ring, clamp, chain hoist, etc. The rest of the filter bag dust collector and its accessories are the venturi tube, frame, mouth ofelasticring, etc.
Products Specifications:
| Polyester Needle Punched Filter Bag | |||
| Material | Polyester fiber, polyester short fiber | ||
| Weight(g/m²) | 500-700 | Thickness(mm) | 1.7-2.5 |
| Air permeability (m³/m²•min) |
6-24 | Working temperature (DryºC) | Continuous 130 |
| Instantaneous 150 | |||
| Diameter & Length | No limited | Surface treatment | Heat-setting, PTFE paint-coating, Singeing, Surface anti-static, Water and oil repellent treatment |
| Tension break(N/5*20cm) | Warp≥800 | Break elongation (%) | Warp≤35 |
| Weft≥1000 | Weft≤45 | ||
| Resistance to acid | Fair | Resistance to alkali | Fair |
| Resistance to oxidation | Good | Resistance to hydrolysis | Poor |
Features of Polyester Filter Bag:
· High Durability membrane technology provides an excellent combination of filtration efficiency, airflow, and durability.
· Polyester fibers provide good all-around chemical resistance, especially in applications operated below 79°C.
· Special multifilament scrim design provides excellent dimensional stability and resistance to mechanical damage over the life of the filter.
· More options for coatings, finishes, sizesandconfigurations.
· More choice for singed, glazed, PTFE, anti-static, fire-retardant,oleo-phobic, acid resistant.
Application Fields:
1. The fume and smoke treatment and particle removing system in metallurgy plant, alloy plant, steel works, fire-retardant factoriesandpower stations.
2. Fume filtration, tiny particle recycle and division of liquid and solid inaluminumelectrolytic analysis, tin, zinc,cooperand other rare metals.
3. Smoke filtration in garbage burning, coal-feed boiler and liquidized laid boilers.
4. Division of liquid, solid and tiny particle recycle in chemicals, coke, carbon, dyestuff, pharmacyandplastics.
5. Asphalt concrete mixture,cements, ceramics, building materials, limeandplaster.
6. Dust treatment, purificationandcollection in electronics, mining, foodstuff processing, flour and timber processing.
FAQ:
1. How to choose material for filter bag with good price?
Since every filter has its own characteristics andparameters,when we choose filter material for dust collector filter bag, we have to know the following parameters:
(1) Working temperature
(2) Humidity
(3) Dust diameter
(4) Gas' chemical properties
(5) Dust abrasiveness
(6) Filter's mechanical parameters
2. How to assure the product quality?We will send the sample for your confirmation first, and then produce the products according to your requirement.
3. Can you provide free sample?
Normally, our sample fee is free if its value is less than $5.
However, you have to pay us the courier cost like: DHL, FEDEX, UPS, TNT...
4. Generally, what is the delivery?
In normal circumstances, the products can be delivered within 2 week after your deposit.
5. Why aren't my bags lasting as long as they used to?
Bag's life is limited by the amount of dust captured, not by hours they are used. Bags filtering clean working environment may last a year. A bag filtering high dust containing plant may only last a few weeks. A product can appear clean to the naked eye and still be full of particles that are too small to see.
6. How do I know when to change bags?
Monitor the inlet pressure. The pressure drop across a bag rises as the active surface area is used up. When the pressure starts toraisefaster the bag is almost used up and should be changed. Every application is different, but a good rule of thumb is to change bags when you see 8-12 PSI pressure drop (the difference in pressure between the filter's inlet and outlet).
