Product Description:
This series three in one JPMX-303ESK Hydraulic Multi Working Copper Busbar Machine has three units:punching, shearing and bending.
Processing material:
Copper and Aluminum Busbar.
Copper or aluminum round bars.
Main Functions:
1. Bending Busbar / bars. ( horizontal and vertical direction are available.)
2. Punching Busbar / bars. ( Round hole, oval hole, square hole are available.)
3. Cutting busbar. (Cutting busbar without waste. )
4. Special functions with customized toolings.( embossing, knurling, twisting, cable joints pressing )
1. Cutting unit:
Cutting busbar without waste.
2. Punching unit:
Turret punching structure. Install 6 punching dies at one time.
Round dies, oval dies, square dies are available.
Dies sizes customized.
3. Bending unit
This machine can make three kinds of bending.
Vertical bending, horizontal bending, U shape bending.
The bending angle precision is controled by PLC.
It is easy operated even for new worker.
Detailed Parameters:
Function |
Item |
JPMX-303ESK |
Punching |
Max. Punching Force (KN) |
300 |
Punching Diameter Range (MM) |
Ø4.3-Ø25 |
|
Max. Thickness (MM) |
12 |
|
Max. Width (MM) |
160 |
|
Shearing/Cutting |
Max. Shearing Thickness (MM) |
12 |
Max. Shearing Width (MM) |
160 |
|
Vertical Bending |
Max. Bending Force (KN) |
300 |
Max. Thickness (MM) |
12 |
|
Max. Width (MM) |
160 |
|
Horizontal Bending |
Max. Width (MM) |
100 |
Max. Angle (Degree) |
90° |
|
Out Dimension |
MM |
1800*1400*1480 |
Power |
KW |
3*4kw |
Weight |
KG |
1420kg |
CNC Precision |
Bending Precision |
±1° |
Repeat Bending Precision |
±0.3° |
