General information:
SXJB-II is designed with advanced power technology, have full function, reliable material, clear test items data, easy to operate. It's the first choice for electric power replay divisions.
Features:
√ Measuring relay: To measure the starting value, returned value and returned factor of current/ voltage relay.
√ Time relay: To measure the starting value, returned value and action time.
√ Intermediate relay: To measure starting value, returned value, keeping value and action time of various intermediate reply with starting and holding coil.
√ Reclosing relay: Capacitor charging test, charging test, reclosing time and intermediate unit test.
√ Differential relay: DC exciting test, braking characteristic test, volt-ampere characteristic test.
√ And others unusual relays.
Specifications:
Working condition | |
| Power supply: | AC220V+10% 50Hz |
| Temperature: | -10ºC~40ºC |
| Humidity: | ≤85% |
| Atmosphere: | 86~106Kpa |
| Output supply | |
| AC Voltage: | 0~220V/3A |
| AC Current: | 0~100A/7.5V |
| 0~20A/25V | |
| 0~5A/5V | |
| DC Voltage: | 0~220V/3A |
| DC Current: | 0~20A/25V |
| Fixed Output: | DC24V DC48V DC110V DC220V |
| Current/Voltage meter: | 4 1/2 digits |
| Digital millisecond meter: | 0~99.9999s |
Warranty: One year quality guarantee after shipment.
More information, please kindly contact with us, we can customize the suitable test set according your requirements and give you the best quotation. Thank you!
