General information:
SXTC-A Series AC/DC Hipot Test Set is suitable for hipot dielectric withstand test on various power electric products, units, insulating material and etc.
Features:
√ Automatic or manual control mode can be selected
√ Oil, dry, SF6 gas type transformer is selectable according to user's requirements.
√ LCD screen, thermal printer.
√ 3 channels/4 channels/ 8 channels or more channel tests can be selected.
√ HV voltage/current, LV voltage/current, time and withstand result can be displayed clearly.
√ Full over voltage/current protection, can set output voltage, hV current limitation, LV current limitation and timekeeping.
√ Voltage increasing or decreasing can be paused during automatic testing.
√ Zero start protection. The test could be proceed only after voltage is back to zero.
√ The voltage output could be stopped automatically when the HV current or LV current is over setting value, voltage is back to zero and sound-light alarming.
√ When the voltage reaches setting value, timing starts automatically. The voltage is auto decrease back to zero after timing up.
√ To press Exit to quit test at any time. To press Emergency to cut off voltage output.
√ High anti interference design.
√ Auto error diagnostics, easy to find and resolve the problem.
√ AC or AC/DC test is selectable.
√ 5kVA and above Testing Transformer with movable iron wheel. Light weight, small size, easy to move, superior performance.
√ The control tester can be designed to box type, table type, or cabinet type according to user's testing capacity:
5KVAor below, Box type
10KVAor above Table type
50KVAor above Cabinet type.
Specifications:
√ Input voltage: AC 220(380)V (customized)
√ LV output: AC 0-250(430)V
√ LV current: 0-5/10/15/50A (customized)
√ Output capacity: 0-3/5/10/15 kVA (customized)
√ HV output: 0-50/100/150/200 kV (customized)
√ HV current: 0-50/100/150/200/500/1000/2000mA (customized)
√ Timing range: 0-9999S
√ Working temperature: -20ºC to 50ºC
√ Voltage precision: ≤1.5% ±1 digit (F.S)
√ Current precision: ≤1.5% ±1digit (F.S)
Models For Reference:
| Model |
KVA |
Power Supply | Output | Weight | Mark | |||
| Phase | (V) | (A) | (V) | (A) | ||||
| SXTC-A 2/220 | 2 | 1 | 220 | 50 | 0-220 | 10 | 14 | |
| SXTC-A 3/220 | 3 | 1 | 220 | 50 | 0-220 | 15 | 16 | |
| SXTC-A 5/220 | 5 | 1 | 220 | 50 | 0-220 | 25 | 18 | |
| SXTC-A 10/220 | 10 | 1 | 220 | 50 | 0-220 | 50 | 80 | |
| SXTC-A 15/400 | 15 | 2 | 380 | 50 | 0-430 | 37.5 | 90 | |
| SXTC-A 20/400 | 20 | 2 | 380 | 50 | 0-430 | 50 | 100 | |
| SXTC-A 25/400 | 25 | 2 | 380 | 50 | 0-430 | 62.5 | 120 | |
| SXTC-A 30/400 | 30 | 2 | 380 | 50 | 0-430 | 75 | 140 | |
| SXTC-A 50/400 | 50 | 2 | .380 | 50 | 0-430 | 125 | 160 | |
| SXTC-A 100/400 | 100 | 2 | 380 | 50 | 0-430 | 250 | 50 | To be equipped with regulator |
| SXTC-A 150/3000 | 150 | 2 | 380 | 50 | 0-430 | 50 | 50 | |
| SXTC-A 200/3000 | 200 | 2 | 380 | 50 | 0-430 | 65 | 50 | |
| SXTC-A 250/3000 | 250 | 2 | 380 | 50 | 0-430 | 84 | 50 | |
| SXTC-A 300/3000 | 300 | 2 | 380 | 50 | 0-430 | 100 | 50 | |
Accessories for option:
√ AC DC divider 50,100,150,200kV
√ Sphere gap
√ DC microammeter
√ Discharge rod
√ Water resistor
√ HV filter capacitor: 0.01μF-0.1μF, 40-300kV
√ Trolley
√ Insulating support: 50,100,200,300kV
√ Oil cup: 400ml
√ HV electroscope: 10, 35kV
Please contact with us for further information, our technically expereinced expertise team will select correctly designed test set for you.
Warranty: One year quality guarantee after shipment.
Please contact Sansion Power Electric for details information, we can select correctly designed products for you.
