1. The applications of XYX-130 wheeled drilling rig
Field irrigation well, civil uses water well and so on; geological survey and exploration, basic exploration for roads and high-rise buildings, inspection holes for various concrete structures, river embankments, subgrade grouting holes.
2.The features of XYX-130 wheeled drilling rig
l The rig is equipped with a wheeled walking mechanism, which is convenient for the whole machine to move
l With oil pressure feeding mechanism to improve drilling efficiency.
l The drill rig is equipped with a ball card holding mechanism instead of chuck, and it can be operated without stopping the rod. The working efficiency is high and the operation is convenient and safe and reliable.
l Pressure gauges with hole bottom indicate pressure, so as to facilitate the control of the situation in the hole.
3.The specifications of XYX-130 wheeled drilling rig
XYX-130 wheeled drilling rig | |
Drilling depth |
130m |
Maximum open hole diameter |
220mm |
End hole diameter |
75mm |
Drilling pipe diameter |
50mm |
Drilling angle |
90°-75° |
Drill rig weight |
950kg |
Vertical Spindle | |
Spindle rotating speed |
142 285 570r/min |
Spindle stroke |
450mm |
Windlass | |
Maximum lifting weight of single rope |
1600kg |
Maximum lifting speed of single rope |
0.41/ 0.82/1.64m/s |
Drum diameter |
140mm |
Wire rope diameter |
13mm |
Drum capacity |
27m |
Mud pump | |
Model |
Horizontal single cylinder double action |
Displacement (diesel and electric engine, respectively) |
95/77 l/min |
Maximum pressure |
1.2mpa |
Working pressure |
0.7mpa |
Water inlet pipe diameter |
30mm |
Water outlet pipe diameter |
20mm |
Triangular belt diameter |
B1575mm |
