Help CenterHZ-200Y Hydraulic Well Drilling Rig
Related Products
-
HZ-200YY Hydraulic Water Well Drilling RigUS$ 5000 - 6000MOQ: 1 Set -
XYX-200 Wheeled Water Well Drilling RigUS$ 5000 - 6000MOQ: 1 Set
-
XYD-200 Crawler Water Well Drilling RigUS$ 5000 - 6000MOQ: 1 Set
-
XYC-200Hydraulic Water Well Drilling RigUS$ 5000 - 6000MOQ: 1 Set
-
BXZ-1 Portable Backpack Core Drilling Rig Operated By One PearsonUS$ 5000 - 6000MOQ: 1 Combo
1. The applications of HZ-200Y hydraulic water well drilling rig
Made in China water well,field irrigation well, engineering water well,precipitation well and so on; geological survey and exploration, road and high-rise building foundation exploration, and all kinds of concrete structure inspection holes, river embankments, subgrade grouting holes, drilling and direct grouting.
2.The features of HZ-200Y hydraulic water well drilling rig
l 53 x 59 drilling rod adopted, high rigidity and strong delivery torque
l The machine is equipped with national patent technology---taper clutch, with characteristics of strong transmission torque, easy operation and free maintenance.
l For the winch, we use large module planetary gear and add supporting frame, greatly increasing hoisting and braking ability of the winch.
l Vertical spidle are fixed by four groups of bearings to ensure that the rotary machine is rigid enough for gravel layer and other complex geoloical conditions.
l We are the first one to equip mud pump with the flow 160L/min in China .So the features will achieve cost saving, compact structure and portable.
3.The specifications of HZ-200Y drilling rig
HZ-200Y drilling rig | |
Drilling depth |
200m |
Maximum open hole diameter |
300mm |
End hole diameter |
75mm |
Drill pipe diameter |
50mm |
Drilling angle |
90° |
Drilling rig weight (excluding power) |
1100kg |
Triangular belt |
B950×4 B1700×3 |
Active move range |
300mm |
Power |
Diesel engine 20HP Electric motor 15kw |
Spindle | |
Spindle rotating speed |
64 128 287 557 r/min |
Spindle stroke |
450mm |
Windlass | |
Maximum lifting power of a single rope |
2400kg |
Maximum lifting speed of a single rope |
0.41/0.82 /1.64m/s |
Wirerope diameter |
13mm |
Drum capacity |
35m |
Band type break diameter |
260mm |
Band type break belt width |
70mm |
Mud pump | |
Model |
horizontal single-urn twin-action |
Displacement |
diesel engine 170L/min electric motor 150L/min |
Maximum pressure |
3mpa |
Work pressure |
1.5mpa |
Water inlet pipe diameter |
40mm |
Water outlet pipe diameter |
30mm |
Triangular belt |
B1728mm |
Mud pump | |
Type |
CBT—F—314 |
Triangular belt |
B1100× 1 |
