Oil Well WECO Union Adapter Flange 2-1/16" 5K WP FLANGE 2" WECO FIG. 1502
2" Fig 1502 Weco Union Adapter Flange API 6A Wellhead
Overview of the Weco union adapter flange
Thhe Weco union adapter flange is composed with the flange adapter and the weco hammer union. Wellhead flange adapters are designed to be installed on to API wellheads and provide a transition between the xmas tree and the well intervention pressure control equipment. It is important to note that, the wellhead flange adapter should always be compatible with the through bore of the wellhead it is being installed on to.
Features of the Weco union adapter flange
* Made of AISI 4130 Forging
* The adatper flange with union connection is easy to be installed with the other wellhead equipmets.
* Reliable quality, conformed with API standard
* The adatper flange can be worked in H2S condition according to NACE MR0175
Detailed Specification of the adatper flange
Item | Description |
1 | WECO UNION ADAPTOR FLANGE * C/W 2" WECO BLANKING PLUG WITH 1/2" NPT PORT * MATERIAL: AISI 4130 |
2 | WECO UNION ADAPTOR FLANGE |
JC wellhead factory manufactures the Weco Union Flanges in both Female and Male connection, the weco sizes range from 1-13/16" all the way up to 4-1/16" with varying pressures starting at 3000psi to 15000psi. And pressure tested of the flange adatper, certified and monogrammed to API specs, suited for H2S service NACE MR-0175. The material grade AISI 4130 75K PSL 2 PR1 DD, U, NACE MR0175
Oil Well WECO Union Adapter Flange 2-1/16" 5K WP FLANGE 2" WECO FIG. 1502
2" Fig 1502 Weco Union Adapter Flange API 6A Wellhead
Send Inquiry to This Supplier
