Home > Instruments & Meters > Optical Lens & Instrument > Optical Lens > Automatic CNC Video Measuring System VMC Series

Automatic CNC Video Measuring System VMC Series

Name: Automatic CNC Video Measuring System VMC Series
Brand: YIHUI
SKU: 159077239
Availability: InStock

Automatic CNC Video Measuring System VMC Series thumbnail-1

Automatic CNC Video Measuring System VMC Series photo-1

US$ 11000 - 28000 MOQ: 1 Set

Key Specifications

Get Latest Price

Brand Name:

YIHUI

Place of Origin:

China

Model Number:

VMC3020

Contact Supplier Request Quote Chat Now

Dongguan Yihui Optielectronic Technology Co., LTD

Payment & Shipping

Payment Methods:

Port of Shipment:

shezhen

Delivery Detail:

10 days

Product Details
Company Profile
Contact Us

Brand Name YIHUI

Place of Origin China

Model Number VMC3020

Automatic CNC Video Measuring System VMC Series

Features

1. Double closed-loop motion control, embedded modules developed to control motor with precise positioning performance.

2. Surface light formed by 24 groups independent light source, each group are constant current source driver and 200-step continuous variable.

3. Optical measurement system can measure point, line, circle, arc and oval, rectangular with the multi-point positioning function, combination of measurements, center structure and the intersection of structure, the midpoint of construction, line structure, around structure.

4. High Accuracy CNC optical measurement machine has various functions of data processing, display, input and output, Measurement data output Word, Excel and AutoCAD directly to conduct statistical analysis, particularly, the work piece straightening function is very useful.

5. Macros will be faster and more convenient to measure the same spare parts, for the improvement of measurement efficiency.

Usage

VMC Series is a high precision type CNC video measuring system produced by YiHui. It has been widely used in machinery, electronics, metalwork, plastics, mould, and other industries for precision automatic measurement.

Specification

Model		VMU3020		VMU4030	VMU5030
Worktable	Work table’s size(mm)	600*390		700*490	800*490
	Glass table’s size(mm)	350*250		450*350	550*350
	X,Y stroke (mm)	300*200		400*300	500*300
	Z stroke (mm)	200(Focus)		200(Focus)	200(Focus)
	X.Y.Z-axis scale resolution	1um		1um	1um
	X.Y coordinates indication error	≤(2.8+L/200)um (L be regarded as length, unit:mm
	Instrument Weight (kg)	440		560		580
	Dimension (mm)	14009001780		160011201780		165011201780
Motor	Three-axis velocity			X,Y:400mm/s Z :200mm/s
	Three-axis positioning accuracy			0.001mm
Imaging System	Camera		TEO Color 1 / 2 "CCD Camera
	Zoom lens		Auto zoom lens
	Zoom lens magnification		0.7-4.5X
	Total magnification		20-128X
	Object field		11.1-1.7mm
	Power		AC220V/AC110V
	Power consumption		600W
