Peel strength tester
Uses
This machine is designed for quick and reliable tensile, compression, bending, shear, peel, loop tack and fatigue cycling on metals, tape, composites, alloys, rigid plastics and films, elastomers, textiles, paper, board and finished products.With longer stroke,can meet bigger elongation products need,like film,fabric,rubber,textiles.....
Character
Have steady performace, high accuracy, and easy operation.
Accessories
1.Suitable Grips that meet customer sample need.
2.Special peeling tools for peel test in tape&film industry.
3.English operation teach video.
Specifications
Design Standards |
ASTM D903，GB/T2790/2791/2792，CNS11888，JIS-K6854，PSTC7
|
Model |
JY-1015
|
Capacity |
1、2、5、10、20、50、100、200kg optional |
Stroke |
1200mm |
|
Range of speed |
50～500mm/min adjustable,constant speed， 300mm/min |
Test space |
120mmMAX |
Accuracy |
±1.0%
|
Resolution |
1/150,000 |
Motor |
adjustable speed motor |
Display |
force and elongation display |
Dimention |
(W×D×H)60×60×180cm |
Optional accessories |
stretcher, air clamp |
Weight |
60kg |
Power |
1PH, AC220V, 50/60Hz |
Safety Device:
Stroke protection: Machinery, computer double protection, prevent over preset
Emergency stop device: Handling emergencies.
