Home > Products > extrusion coating and lamination machine > Yilian brand SJFM1100-2000 kraft paper PE extrusion coating machine
Yilian brand SJFM1100-2000 kraft paper PE extrusion coating machine
- 30 Set / Sets per Month
- NINGBO
- T/T L/C Cash
- 45 days
-
Economical, Efficient and Energy-Saving Manual Screen Printing PU Scraper Cleaning Machine
-
Tamprinter glitter powder machine The operating principle
-
flame treatment machine TM-F4 car bumpers flame processor equipment
-
Air-Gas burner Bottle flame treatment machine with automatic ignition
-
Manufacturer Wholesale Custom Tamprinter glitter powder machine
-
Factory Supply Tamprinter Squeegee Clean machine for sale
Product Details
| Brand Name: | YILIAN | Place of Origin: | China | Model Number: | SJFM1100-2000 |
| Certification: | CE | After-sales Service Provided: | Engineers available to service machinery overseas | Weight: | 15T |
| Dimension(L*W*H): | 9600*8600*3600MM | Voltage: | 380V,3PH | Power: | 60-80KW |
| Application: | Beverage, Food | Condition: | New | Automatic Grade: | Semi-Automatic |
| Driven Type: | Electric | Packaging Material: | Plastic, Wood | Packaging Type: | Other, STANDARD EXPORT PACKING |
Product Description
Main features:
Sjfm series green laminator, paper plastic composite units (no adhesive composition unit): set discharge, drying, surface treatment, composite, cutting edge, suction side, volume as a whole; the photoelectric error correction, corona treatment, line speed, feed length digital display; automatic constant tensile force, temperature control and advanced technology.
Application:
paper cups, fast food boxes,cement chemicals packing, food packing, medicine packing, cloth tape, and other packaging materials.
Features:
1.PLC man-machine interface centralized control, machine, electricity, gas, integrated design.
2 high efficient corona device
3. Easy and quick filter screen exchange
Form of production:
Single-layer lamination / three layer composite multilayer composite (Jia Xin) / (one-time seven layers, increase the extrusion unit)
Main technical parameters:
| model | SJFM-800 | SJFM-1100 | SJFM-1300 | SJFM-1600 | SJFM-1800 |
| lenght of die lip | 900mm | 1200mm | 1400mm | 1800mm | 2000mm |
| width of finished product | 400-700mm | 500-1000mm | 600-1250mm | 800-1500mm | 900-1700mm |
| Max. Coating speed | 100-150m/min | 100-150m/min | 100-150m/min | 100-150m/min | 100-150m/min |
| thickness of shower film | 0.01-0.1mm | 0.01-0.1mm | 0.01-0.1mm | 0.01-0.1mm | 0.01-0.1mm |
| L/D ratio for screw | Φ80mm×30 | Φ95mm×30 | Φ105mm×30 | Φ120mm×32 | Φ140mm×32 |
| diameter for roll unwinding and rewinding | Φ1300mm | Φ1300mm | Φ1300mm | Φ1300mm | Φ1300mm |
| overall size | 9600×8000×3200mm | 9600×8300×3200mm | 9600×8600×3200mm | 9600×9000×3200mm | 9600×9300×3200mm |
| power | 60kw | 70kw | 80kw | 100kw | 130kw |
| compounding/glossy cool roll | Φ510mm | Φ510mm | Φ510mm | Φ510mm | Φ610mm |
| applicable for base material | Paper/non woven pp/woven sack | ||||
