pdc polycrystalline diamond compact pcd cutter
- 5000 Piece / Pieces per Month
- shenzhen
- T/T L/C D/P D/A Credit Card PayPal Other Cash Escrow
- 7 days
Product Details
Brand Name: | More | Place of Origin: | China | Model Number: | PCD |
Size: | Vairous | Type: | Other, PCD tool |
Product Description
Oil drilling tools PDC insert, PDC cutters
PDC Cutter Geology Industry
Oil Pdc CUTTER suitable for soft to medium hard geological drilling, the impact toughness and high thermal stability, heat resistance temperature can reach 750 ℃, such products have plane and various groove surface combination model, and can design according to customer's need to groove, grinding, polishing and chamfering, etc., can provide products with special shape.
PDC Cutter Etroleum Industry
suitable for cutting high hardness alloy, wood, ceramic and other non-metallic, nonferrous metal and other metal cutting and processing, has the high hardness and wear resistance, high cutting precision, at the same time according to user needs, will be growing product processing square, triangle, fan and other shapes, can be used to make wear-resisting devices, etc.
Specifications of PDC Cutter
Pdc cutter | Size | 0804 | 0808 | 1004 | 1008 | 1304 | 1308 | 1313 | 1608 | 1613 | 1616 | 1913 | 1916 |
D(mm) | 8.00 | 8.00 | 10.00 | 10.00 | 13.3 | 13.44 | 13.44 | 16.00 | 16.00 | 16.00 | 19.05 | 19.05 | |
T(mm) | 4.00 | 8.00 | 8.00 | 8.00 | 8.00 | 8.00 | 13.20 | 8.00 | 13.20 | 16.00 | 13.20 | 16.00 |
PCD cutter detection requirements
Using the surface hardening technology to improve wear resistance by 200%. Using 10 million mpa superhigh pressure technology can make the shock resistance of up to 80 j.
Our Advantage of PDC Cutter
We have 10 years focused on the production of 1313 and 1308. Serve the mining, oil and gas drilling. TG series of TG and IT two, high wear resistance, used in wear-resistant layers of quartz sandstone and impact resistant performance is good, IT is mainly used for granite, gravel strata.
