The stirrer of LB3000CN asphalt mixing plant adopts the spiral twin-shaft forced stirring method, and the rated productivity can be achieved when the filling rate is 45%; the synchronous drive dual-shaft stirring system with the latest concept, the centralized lubrication system, the imported reducer, as well as the use of imported bearings, it created a boutique in the asphalt mixing tank. The high-speed PLC is used as the control system of the equipment to control the production process of the equipment. The program fully uses the EPROM storage technology to make the program storage more stable and reliable, and the zero-failure system concept can be realized. The architecture adopts a modular hardware structure. The microcomputer monitoring and touch screen monitoring are independent of each other. One system fails and the other system can work , ensure that the equipment does not stop.
The J3000 containerized asphalt mixture mixing equipment developed by our company is to meet the rapid development of China's highway construction and the need for maintenance of high-grade highways. It is urgent to produce high-level, large-scale production, convenient transportation and installation, and meet the national environmental protection requirements. Asphalt mixing equipment. It is mainly applicable to the construction and maintenance of high-grade highways, airports, ports and municipal roads. Its main features:
(1) Containers and modular structures provide fast transportation and rapid transition.
(2) Easy installation and disassembly saves time for installation and commissioning.
(3) Advanced automatic control and monitoring systems make the equipment more reliable.
Main technical parameters of LB3000CN asphalt mixing plant
Model LB3000CN
Productivity (t/h) 240 (standard conditions)
Measurement accuracy Aggregate (%) ±0.5%
Powder (%) ±0.25%
Bitumen (%) ±0.25%
Dust blackness Ringgmann blackness ≤1
Dust removal effect (mg/Nm3) ≤100
Dimensions (m) 49x31x26
Machine quality(t) 380
Installed capacity (kw) 671
Room noise (dB) ≤75
Environmental noise (dB) ≤85
Temperature control error Output temperature can be arbitrarily set
Temperature control error microcomputer automatic control, electrical operation with manual overload control
