LB-5000 Asphalt Mixing Plant

The asphalt mixing plant can produce asphalt mixture, modified asphalt mixture and colored asphalt mixture, which fully meets the needs of plant highways, grade highways, municipal roads, airports and ports. It is a factory-type complete set of equipment that mixes dry and heated aggregates of different particle sizes, fillers, and bitumen into uniform mixes according to the design mix ratio and is widely used in high-grade highways, urban roads, airports, and docks. Parking lot and other engineering construction. It is the first key equipment for asphalt pavement construction and its performance directly affects the quality of asphalt pavement.

The equipment of the LB5000 asphalt mixing plant adopts the modularization, standardization, generalization, and intelligent design concepts, and it pays attention to environmental protection and energy conservation. The main features of its equipment:

(1) Computer automatic process control

(2) Digital frequency conversion burner technology can use heavy oil, residual oil

(3) German vibratory screening technology, grade 6 aggregate screening

(4) Inertia+pulse bag filter ensures strict environmental standards

(5) Suitable for use on any grade of pavement

Main technical parameters of LB-5000 asphalt mixing plant

Model LB-5000

Productivity (t/h) 360-400

Measurement Accuracy Aggregate ±0.5%

Powder ±0.25%

Asphalt ±0.25%

Dust emission concentration (mg/Nm3) ≤ 50 Ringermann black level less than one

Dimensions (m) 85x21x28

Total weight (t) 450

The total capacity (kw) 1050

Cold aggregate volume (m3) 6 x15.5

Drying drum diameter × length 3x12

Shaker frequency (RPM) 1050

Hot aggregate storage capacity (t) 100

Powder silo capacity (t) 2 x40t

Cloth bag filter area (m2) 1320

Finished product silo effective volume (t) 200

Asphalt tank capacity (m3) 4x50
