Help CenterGUVC-T21GH UV Sensor Module
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
Genicom
Place of Origin:
South Korea
Model Number:
GUVC-T21GH
Payment & Shipping
Payment Methods:
Port of Shipment:
HK
Delivery Detail:
7 days
Related Products
-
TOCON_E1 SiC Based UV-Index Photodetector With Integrated AmplifierNegotiableMOQ: 1 Piece -
TOCON_GaP4 GaP Detector With Integrated AmplifierNegotiableMOQ: 1 Piece
-
SG01L-5LENS Concentrator Lens SiC Based UV PhotodiodeNegotiableMOQ: 1 Piece
-
SG01M-18 Broadband SiC Based UV Photodiode A = 0. 20 Mm2NegotiableMOQ: 1 Piece
-
GenUV-L365P-MM Reflective UV Sensor for Money DetectingNegotiableMOQ: 1 Piece
Brand Name
Genicom
Place of Origin
South Korea
Model Number
GUVC-T21GH
Usage
Other, UV Sensor
Theory
Optical Sensor
1. UV Sensor Module GUVC-T21GH Features
Single Supply Voltage Operation
Amplified Voltage Output
High Sensitivity and Good Solar Blindness
Small and Compact Size
2. UV Sensor Module GUVC-T21GH Applications
Pure UV-C Monitoring
Sterilization Lamp Monitoring
3. UV Sensor Module GUVC-T21GH Outline Diagrams and Dimensions
4. UV Sensor Module GUVC-T21GH Absolute Maximum Ratings
Storage Temperature: -40~90℃
Operating Temperature: -30~85℃
Supply Voltage: 5.5V
Soldering Temperature: 260℃
5. UV Sensor Module GUVC-T21GH Characteristics (at 25℃)
Supply Voltage: 1.8~5.5V
Supply Current: 50µA
Responsivity: 0.6mV/nW
Spectral Detection Range: 220~280nm
Output Voltage: 0.355V
Offset Voltage: 0.01V
Detection Power Range: 0~14.1mW/cm2
Rising Time: 3ms
Storage Temperature: -40~90℃
Operating Temperature: -30~85℃
Supply Voltage: 5.5V
Soldering Temperature: 260℃
5. UV Sensor Module GUVC-T21GH Characteristics (at 25℃)
Supply Voltage: 1.8~5.5V
Supply Current: 50µA
Responsivity: 0.6mV/nW
Spectral Detection Range: 220~280nm
Output Voltage: 0.355V
Offset Voltage: 0.01V
Detection Power Range: 0~14.1mW/cm2
Rising Time: 3ms
